Specifications
Brand Name :
Melton
Certification :
GMP/ISO/CE
Place of Origin :
Changhzou, China
Supply Ability :
5 Set/Sets per Month
MOQ :
1 Sets
Packaging Details :
fluid bed dryer packed by wooden case
Model Number :
FL
Price :
US $4,500-67,999 / Piece
Payment Terms :
L/C, D/P, T/T
Delivery Time :
5-8 work days
Model :
Customized
Capacity :
1.5~500kg/Batch (Customized)
Size of Granules :
20~80 Meshes
Power Source :
220V/ 380V/ 400V/ 415V/ 440V (50Hz/ 60Hz)
Control System :
Button Type or Touch Screen
Filter :
Pre, Middle and High Efficient Filter
Working Temperature :
40~120 Celsius Degree
Warranty of core components :
1 years
Application :
Pharmacy and Chemical Granulating
Product Collecting Rate :
Over Than 99%
Description

Pharmaceutical Food Chemical Medicine Protein Solid Beverage Dietary Supplements Fluid Bed Granulating Machine

Simple Description

Fluid bed granulator is also called one step granulating machine, it is the use of adhesive bonding effect, make mutual bridge between solid powder, reunion, and gradually formed particles.

Operating

The powder granule in fluid bed appears in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive is sprayed into the container. It makes the particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.

Application
1.Drugs granulation and coating.

2.Granulation: Tablet particles, granule particles, capsule particles.

3.Coating: particles, pill covers, color-prepared, slow-release, films, enteric coating.

4.Food granulation and coating Granulated sugar, coffee, cacao powder, cream, juice powder, amino acids, sauce, puffed food.

5.Pesticide, paint pigment, dry granulation Powder, granules, block materials.

Features

1,The structure of fluid bed is round so as to avoid dead corner；

2,Fluidized drying,heat mass transfer is fast；

3,Operate under closed and negative pressure,no dust flying；

4,Adopt antistatic filter material,operate safety；

5,Meet the GMP specification requirement；

6,The drying speed is fast and the temperature is uniform. In general the drying time is 15-45 minutes for minutes for each batch.

Product Details

Technical parameters

Spec. 3 5 30 60 120 200 300 500 1000
ltem unit .
Container of raw material
Production capacity		 dim. mm 300 400 700 1000 1200 1400 1600 1800 2200
volume L 12 22 100 220 420 670 1000 1500 2500
Min kg/batch 1.5 4 15 30 80 100 150 250 500
Max kg/batch 4 6 36 72 140 240 360 600 1100
Consume of steam kg/batch 12 23 70 140 211 282 366 465 800
Amount of compressed air m³/min 0.3 0.3 0.3 0.6 0.6 0.9 0.9 0.9 1.5
Power of fan kw 2.2 4 5.5 11 18.5 22 30 45 75
Temperature ºC Adjustable from ambient to 120
Cllection rate % >99
Time of operation min 15-30(Depends on material)
Content ol final product % ~0.2(Depends on materil)
Noise dB ≤75
Height of main machine mm 2100 2300 2500 3000 3300 3800 4000 4800 6200

Contract Us
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.

Q: What payment terms you take?
A: TT, LC, other terms are also workable.

Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.

Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange
everything for you!

Any other doubts about our machine, please feel easy to contact with us.
