Powder Milk Spray Dryer Used In Pharmaceutical Industry Food Industry 50kg/H
Powder Milk Spray Dryer Used In Pharmaceutical Industry Food Industry 50kg/H
Specifications
Brand Name :
TIANYANG
Model Number :
LT-25
Place of Origin :
China
MOQ :
one
Payment Terms :
L/C, T/T
Delivery Time :
30 Days
Name :
Milk Powder Spray Dryer
Material :
SUS304, SUS316L, Ti
Max. Water Evaporation Capacity :
50kg/h
Warranty :
One year
Inlet Temperature (℃） :
140-350℃
Out Temperature (℃） :
80-90℃
Spray Type :
High Speed Centrifugal Atomizer
Applications :
Dairy Products processing, chemicals processing, plastics processing, food processing, etc.
Transmission Form of Centrifugal Spray Head :
Compressed air drive
Atomization Rotated Speed (RPM) :
21500
Spray Disc Diameter (mm) :
108
Heating Method: :
Electricity + steam, fuel oil, gas, up to the user.
Electric Heating Maximum Power (KW) :
81
Dimensions (L×W×H) m :
3.7×3.2×5.1m
Dry Powder Recovery :
≥95%
Voltage :
110V220V/380V/440V/Customization
Core Components :
Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine
Use purpose :
Lab or pilot
Description

7.Centrifugal Spray Dryer for Milk Powder

Product Description

LT-Series high speed centrifugal spray drying machine is suitable for various fields where the production of a powder is required.

LT-50KG high speed centrifugal spray dryer has successfully processed in the following areas: milk powder, dairy products, egg products, beverage, flavours and colourings, plant and vegetable extracts, pharmaceuticals, perfumes, blood, ceramics and superconductors biochemicals, dyestuffs, soaps and detergents, foodstuffs, adehesives, oxides, textiles and many others.

LT-50 milk spray dryer machine adopts PLC automatic control. All operations are completed automatically according to the process parameters set by users. It fully meets the requirements for milk powder processing production in GMP.

LPG series high speed centrifugal spray dryer machine
(Spray drying)Atomizing drying machine is the high efficient drying equipment, to make dry powder or granule from liquid, emulsion, suspension and pumpable pasty liquid, especially for thermosensitive material, it can keep color, original flavor and chemical feature of raw material, and the finished dry powder or granule have good quality,purity, fluidity andsolubleness.
This equipment features by high accuracy & speed & efficiency, simple production process, labor-cost saving, widely applied in the industry of chemical, food, pharmacy, biochemistry, light industry,etc.
Description :
After fresh air is filtered and heated,it enters into the air distributor which on the top of the drier.The hot air in spiral form equably enters into the drying room.When liquid raw material arepassed through the high-speed centrifugal sprayer on the top of the tower,it will be rotated and sprayed into the extreme slim mist liquid beads.Raw material can be dried to the final products instantly while it contact with the heatedair.Finished products are discharged continuously from bottom of the drying tower and cyclones segregator. Wasted air is discharged from blower.

Powder Milk Spray Dryer Used In Pharmaceutical Industry Food Industry 50kg/HPowder Milk Spray Dryer Used In Pharmaceutical Industry Food Industry 50kg/H

Technical Specifications of Spray Dryer for Milk Powder

Model LT-50
Max. Water Evaporation Capacity (kg/h) 50kg/h
Material SUS304, SUS316L, Ti
Inlet Temperature (℃) 140-350℃
Out Temperature (℃) 80-90℃
Spray Type High Speed Centrifugal Atomizer
Applications Dairy Products processing, chemicals processing, plastics processing, food processing, etc.
Transmission Form of Centrifugal Spray Head Compressed air drive
Atomization Rotated Speed (RPM) 21500
Spray Disc Diameter (mm) 108
Heating Method Electricity + steam, fuel oil, gas, up to the user.
Electric Heating Maximum Power (KW) 81
Dimensions (L×W×H) m 3.7×3.2×5.1m
Dry Powder Recovery ≥95%

Features and Benefits

* Special protection function,the fan will not startand the heater will not start

* Built-in imported oil-free air compressor with noise less than 50db.

* Equipped with airinlet filter to ensure powder purity.

* Dried product has uniform particle sizemorethan95% of the dry powder is at the same particle size.
