stainless steel wire filter mesh
stainless steel wire filter mesh
Specifications
Place of Origin :
Shanghai China
Brand Name :
SPRING
Certification :
ISO9001
Model Number :
160/1400
Filter Rating :
75%-98%
Thickness :
0.1mm
Length :
30m-70m
Width :
0.6-3.65m
Usage :
Liquid Filter
Type :
Perforated Metal Mesh
Material :
Metal Fiber
Hole Shape :
Square
MOQ :
30m
Price :
www.springscreenmesh.com
Packaging Details :
Paper tube, plastic bag, carton box, sailcloth
Delivery Time :
3-5 Days
Payment Terms :
TT/LC/Western Union/paypal/others
Supply Ability :
10000m/month
Description

Specifications

stainless steel wire mesh filter mesh
ISO9001 ISO14001
302/304/304L/316/314/316L
can be cut into pieces or bag

Stainless Steel Filter Mesh

Application

Filter mesh for gas and liquid serves well in filtering and deleting the particle mixture in foam, liquid and air, by way of distillation, absorbing, evaporating and filtering process, in petroleum, chemicals, metallurgy, machine, pharmaceuticals, automobile and environmental protection.

Specification

  1. Material: 302/304/304L/310/316/314
  2. Weaving: Plain weaving, twill weaving, microgroove-plain weaving, stain weaving, formatted with a lot of burs
  3. Mesh Count: 160~500 mesh
  4. Length: 1~500m
  5. Width: 914~1600mm (some products can reach a width of 4000mm )
  6. Can be cut into coils and pieces according to customers’ requirements

Stainless steel wire can be substituted by copper, galvanized iron wire polyamide fiber or F46 wire if need.

Mesh

Wire Dia(mm)

Opening(mm)

Material(AISI)

2mesh*2mesh

1.8

10.9

304 or 316

3mesh*3mesh

1.5

6.96

304 or 316

4mesh*4mesh

1

5.35

304 or 316

7mesh*7mesh

1

2.63

304 or 316

10mesh*10mesh

0.6

1.94

304 or 316

12mesh*12mesh

0.5

1.62

304 or 316

16mesh*16mesh

0.4

1.19

304 or 316

16mesh*16mesh

0.35

1.24

304 or 316

18mesh*18mesh

0.35

1.06

304 or 316

20mesh*20mesh

0.4

0.87

304 or 316

24mesh*24mesh

0.26

0.8

304 or 316

30mesh*30mesh

0.3

0.55

304 or 316

35mesh*35mesh

0.17

0.56

304 or 316

40mesh*40mesh

0.23

0.4

304 or 316

50mesh*50mesh

0.2

0.31

304 or 316

60mesh*60mesh

0.15

0.27

304 or 316

70mesh*70mesh

0.12

0.24

304 or 316

80mesh*80mesh

0.13

0.19

304 or 316

90mesh*90mesh

0.1

0.16

304 or 316

100mesh*100mesh

0.09

0.15

304 or 316

120mesh*120mesh

0.063

0.12

304 or 316

150mesh*150mesh

0.053

0.11

304 or 316

180mesh*180mesh

0.053

0.09

304 or 316

200mesh*200mesh

0.04

0.07

304 or 316

250mesh*250mesh

0.04

0.063

316

300mesh*300mesh

0.04

0.044

316

325mesh*325mesh

0.035

0.043

316L

350mesh*350mesh

0.03

0.042

316L

400mesh*400mesh

0.03

0.33

316L

450mesh*450mesh

0.028

0.028

316L

500mesh*500mesh

0.025

0.026

316L
