High Efficiency 12v Lead Acid Battery Charge Controller Mppt Solar Regulator
High Efficiency 12v Lead Acid Battery Charge Controller Mppt Solar Regulator
Specifications
Place of Origin :
Guangdong, China
Brand Name :
SRNE
Model Number :
SR-HP2430
Certification :
CE/RoHS/ ISO9001
Supply Ability :
1000 Piece/Pieces per Month
Packaging Details :
Packing:28 pieces for a carton Carton size:590*250*250mm
MOQ :
1
Price :
Negotiable
Application :
Solar System Controller
Maximum Current :
30A
Dimensions :
164.0*103.5*47.0(mm)
USB function :
Yes
Operating temperature :
-25℃~55℃
IP protection degree :
IP30
Overvoltage protection :
16.0V
Charging recovery voltage :
13.2V
applications :
Solar home system and off-grid solar pv system
Temperature compensation :
-3.0mV/℃/2V
Port :
shenzhen
Description

High Efficiency 12v Lead Acid Battery Charge Controller Mppt Solar Regulator

12V/24V voltage high efficiency mppt solar charge controller

Product Description

Features of SR-HP2430/2440
1. An upgraded 3-stage PWM charging algorithm is adopted. Application of an equalizing charge to the battery periodically or when over discharged, can effectively prevent the battery from non-equalization and sulfuration, thus extending the battery's service life (with the exception of GEL and lithium batteries).
2. With temperature compensation employed, charging parameters can be automatically adjusted (with the exception of lithium batteries).
3. A wide range of load working modes facilitate the product's application to different types of street lights and monitoring devices.
4. The product provides overcharge, over-discharge, overload protection, as well as short-circuit and reverse-connection protection.
5. By virtue of an advanced load starting method, large-capacitance loads can be started smoothly.
6. A range of parameter settings and power-down saving functions are available ,thus requiring no repeated setting.
7. Boasting an industrial grade design, the product can function well in various tough conditions.
8. TVS lighting protection is adopted.

Parameter of SR-HP2430/2440

Model

HP2430

HP2440

Rated current

30A

40A

System voltage

Automatic recognition of 12V/24V

Rated power

12V/450W

24V/900W

12V/600W

24V/1200W

No-load loss

< 13mA/12V;< 15mA/24V

Max. Solar energy input voltage

<55

Max. voltage at the battery end

<34V

Overvoltage protection

16.0V

Equalizing charging voltage

14.8

14.6

Boost charging voltage

14.6

14.4

Floating charging voltage

13.8

13.8

Charging recovery voltage

13.2V

Over-discharge recovery voltage

12.5V(settable with the keys)

Over-discharge voltage

11.0V(settable with the keys)

Equalizing charging interval

30days

Equalizing charging time

1H

Boost charging time

2H

Temperature compensation

-3.0mV/℃/2V

Light control voltage

Light control on 5V, light control off 6 V (light control on plus 1 V)

Light control judgment time

10 minutes

USB function

Yes

Operating temperature

-25℃~+55℃

IP protection degree

IP30

Net weigh

390g

Protection functions

attery reverse connection protection, solar panel reverse connection protection Notice 1, reverse charging protection at night ,Charging overload protection, overcurrent protection , short circuit protection

Dimensions

164.0×103.5×47.0(mm)

Detail of SR-HP2430/2440

High Efficiency 12v Lead Acid Battery Charge Controller Mppt Solar RegulatorHigh Efficiency 12v Lead Acid Battery Charge Controller Mppt Solar Regulator
