W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
X120Mn12, 1.3401, ASTM A128, Z120M12, X120Mn13, Creusabro® M
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
600kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
Characteristic :
High hardness
Heat treatment condition :
Cold draw, hot forged, etc
Processing methods :
Machined, Milled, Ground, etc
Available Shapes :
Strips, Wire rod, Sheet Steel, etc
Surface :
Peeled, Black, etc
Description

W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel



Product Information


X120Mn12 is a high manganese steel with an austenitic structure, also a non-magnetic steel, characterized by a high carbon content - 1.00-1.20% on average, and a high manganese content - approx. 12%.


Size Range

Round bar / Wire rod (Diameter): 5.0 mm to 500 mm
Square bar / Flat bar: 1.0 mm to 500 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T3 - 1000 mm X W8 - 1000 mm X L800-12000 mm
Sheet steel via cold rolled: T5.0 - 10 mm X W5 - 1000 mm X L100 - 1000 mm
Steel strip via cold rolled: T1 - 8 mm X W10 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard


X120Mn12/1.3401

GX120Mn13/1.3802

 ASTM A128

--

 -- --


C(％): 1.10~1.30
Si(％): 0.3~0.5
Mn(％): 12.0~13.0
P(％)≤: 0.10
S(％)≤: 0.04
Cr(％): ≤1.5
Ni(％): ≤1.0
Mo(%): -

C(％): 1.05~1.35
Si(％): 0.3~0.9
Mn(％): 11.0~14.0
P(％)≤: 0.06
S(％)≤: 0.045
Cr(％): -
Ni(％): -
Mo(%): -

 C(％): 1.05~1.35
Si(％): ≤1.00
Mn(％): ≥11.0
P(％)≤: 0.07
S(％)≤: -
Cr(％): -
Ni(％): -
Mo(%): -

W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel

X120Mn12/1.3401 Mechanical Properties

Tensile strength, Rm/MPa: ≥900
Yield strength, Rp/MPa: ≥400
Elongation/%: ≥40
Reduction of area, ψ/%: ≥200
Hardness, HBW: --


Applications
X120Mn12/1.3401 is mainly used in crushing and earthmoving equipment in railway and shot blasting industry, primary rock crushing equipment


If you are interested in our products or have any questions, please contact our team of engineers at
sales@ss-bars.com

W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled SteelW-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel


W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
