UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece
UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece
UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece
UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece
UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece
UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AISI 635, UNS S17600
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
800kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
AISI 635 UNS S17600 Stainless Steel Forging Piece
Characteristic :
High hardness, corrosion resistance
Heat treatment condition :
+A, +N, etc
Processing methods :
Milled, etc
Available Shapes :
Flate Bar, Forging piece, etc
Surface :
bright, etc
Description

UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece



Product Information

AISI 635 stainless steel is a high-strength, high-corrosion-resistant stainless steel material belonging to the austenitic series. It is an excellent high-temperature strength steel with good oxidation resistance and thermal stability at high temperatures, as well as good mechanical and corrosion resistance properties.


Size Range

Round bar / Wire rod (Diameter):10.0 mm to 500 mm
Square bar / Flat bar: 5.0 mm to 500 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T3 - 1000 mm X W10 - 1000 mm X L800-12000 mm
Sheet steel via cold rolled: T3.0 - 10 mm X W5 - 1000 mm X L100 - 1000 mm
Steel strip via cold rolled: T0.5 - 10 mm X W10 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

​AISI 635 / UNS S17600
DIN EN 10084-2008

C(％): ≤0.08
Si(％): ≤1.00
Mn(％): ≤0.04
P(％)≤: 0.030
S(％)≤: 1.00
Cr(％): 16.0~17.5
Ni(％): 6.0~7.5
Mo(%): --

Al(％): ≤0.40

Ti(%): 0.40~1.20


UNS S17600 Stainless Steel Sheets Plates AISI 635 Forging Piece

Mechanical Properties

Tensile strength, Rm/MPa: ≥ 1680
Yield strength, Rp/MPa: ≥ 1500

Elongation/%: ≥ 3.50
Reduction of area, ψ/%: --

Impact, KV /J: --
Hardness, HBW: ≤498

Condition +A (1040±15℃) Condition: H950 Condition: H1000 Condition: H1050
Tensile strength, Rm/MPa ≥925 ≥1310 ≥1240 ≥1170
Yield strength ≥515 ≥1170 ≥1100 ≥1035
Elongation/% ≥10 ≥8 ≥8 ≥10
Reduction of area, ψ/% ≥45 ≥25 ≥30 ≥40
Hardness, HB ≥302 ≥363 ≥352 ≥331


Applications

AISI 635 stainless steel is widely used in industrial equipment and chemical equipment under high temperature, high pressure, and corrosive environments, such as furnaces, heat exchangers, steam generators, chemical reactors, etc. It is also used to manufacture high-temperature engine components and aircraft engine turbine blades in the aerospace industry.
