NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
NiCr15Fe, W-Nr 2.4816, Inconel 600, AMS 5665, UNS N06600, JIS NCF600
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
500kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
NiCr15Fe W-Nr 2.4816 Alloy Round Bar
Characteristic :
Corrsion Resistant,
Heat treatment condition :
+AT, +P, etc
Processing methods :
Hot Working, Ground, etc
Available Shapes :
Square bar, Strip steel, Wire, etc
Surface :
Centreless Ground, Grinded, bright
Description

NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel

Product Information

NiCr15Fe/2.4816 is one of the most popular superalloys on the market. It has proven creep and heat resistance, maintaining good mechanical properties at elevated temperatures. NiCr15Fe/2.4816 has good resistance to many high temperature, aggressive chemicals.

Size Range

Round bar / Wire rod (Diameter): 1.0 mm to 1000 mm

Square bar / Flat bar: 8.0 mm to 1000mm

Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled: T5 - 200 mm X W3 - 1000 mm X L1000-12000 mm

Sheet steel via cold rolled: T0.5 - 10 mm X W5 - 1000 mm X L1000 - 1000 mm

Steel strip via cold rolled: T0.3 - 8.0 mm X W3 - 200 mm X L (or in coil form)

Length: Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

NiCr15Fe/2.4816

 Inconel 600/UNS N06600 AMS 5665 JIS NCF600
DIN 17742-2020

SAE J 470c-1976

 SAE AMS 5665N-201 JIS G 4901-2008


C(％): 0.05~0.1
Si(％): ≤0.50
Mn(％): ≤1.0
P(％)≤: 0.02
S(％)≤: 0.015
Cr(％): 14.0~17.0
Ni(％): ≥72.0

Mo(%): --

Cu(%): ≤0.5

Ti(%): ≤0.3

Co(%): ≤1.5

Al(%): ≤0.3

B(%): ≤0.006

Fe(%): 6.0~10.0

C(％): ≤0.15
Si(％): ≤0.50
Mn(％): ≤1.0
P(％)≤: 0.025
S(％)≤: 0.015
Cr(％): 14.0~17.0
Ni(％): ≥72.0

Mo(%): --

Cu(%): ≤0.5

Fe(%): 6.0~10.0

C(％): ≤0.15
Si(％): ≤0.50
Mn(％): ≤1.0
P(％)≤: --
S(％)≤: 0.015
Cr(％): 14.0~17.0
Ni(％): ≥72.0

Mo(%): --

Cu(%): ≤0.5

Fe(%): 6.0~10.0

Co(％): ≤1.0

Nb(％): ≤1.0

Ti(％): ≤0.50

Al(％): ≤0.35

C(％): ≤0.15
Si(％): ≤0.50
Mn(％): ≤1.0
P(％)≤: 0.03
S(％)≤: 0.015
Cr(％): 14.0~17.0
Ni(％): ≥72.0

Mo(%): --

Cu(%): ≤0.5

Fe(%): 6.0~10.0


NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel

NiCr15Fe/2.4816 Mechanical Properties

Tensile strength, σb/Mpa: 550~725

Yield Point, σs/Mpa: 170~345

Elongation, δ/%: 55~35

Reduction of Area,ψ/%: --

Hardness (HB): 65~85

Applications

NiCr15Fe8/2.4816 alloys are used in engine and airframe components such as exhaust liners, turbine seals, furnaces, reactors, and other heat treatment equipment.
