W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar
W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar
W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar
W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar
W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar
W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
W-Nr 2.4610, NiMo16Cr16Ti, Hastelloy alloy C-4, UNS N06455
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
600kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
W-Nr 2.4858 NiCr21Mo Steel Forging Piece
Characteristic :
Corrsion and Heat Resistant
Heat treatment condition :
+QT, +P, etc
Processing methods :
Ground, Cold working, etc
Available Shapes :
Steel plate, Sheet, Coil, Square bar,
Surface :
Rrough Turned, Grinded, Black
Description

W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar

Product Information

W-Nr 2.4858 NiCr21Mo is a nickel-iron-chromium alloy with added molybdenum and copper. It has excellent resistance to reducing and oxidizing acids, stress corrosion cracking, and localized pitting and crevice corrosion, especially sulfuric and phosphoric acids

Size Range

Round bar / Wire rod (Diameter): 5.0 mm to 1000 mm

Square bar / Flat bar: 8.0 mm to 500 mm

Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled: T5 - 200 mm X W3 - 1000 mm X L1000-12000 mm

Sheet steel via cold rolled: T0.3 - 10 mm X W5 - 1000 mm X L300 - 1000 mm

Steel strip via cold rolled: T0.3 - 10.0 mm X W10 - 500 mm X L (or in coil form)

Length: Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

NiCr21Mo/ W-Nr 2.4858

 BS NA16 UNS N08825/Incoloy 825 JIS NCF 825
DIN 17744-2020

BS 3076-1989

 ASTM B424-2011(R2016) JIS G 4901-2008


C(％): ≤0.025
Si(％): ≤0.5
Mn(％): ≤1.0
P(％)≤: 0.02
S(％)≤: 0.015
Cr(％): 19.5~23.5
Ni(％): 38~46

Mo(%): 2.5~3.5

Cu(%): 0.5~3.0

Ti(%): 0.6~1.2

Co(%): ≤1.0

Al(%): ≤0.2

Fe(%): Remainder

C(％): ≤0.05
Si(％): ≤0.5
Mn(％): ≤1.0
P(％)≤: --
S(％)≤: 0.015
Cr(％): 19.5~23.5
Ni(％): 38~46

Mo(%): 2.5~3.5

Cu(%): 1.5~3.0

Ti(%): 0.6~1.2

Ti(%): ≥20C

Co(%): ≤2.0

Al(%): ≤0.2

Fe(%): Remainder

C(％): ≤0.05
Si(％): ≤0.5
Mn(％): ≤1.0
P(％)≤: --
S(％)≤: 0.03
Cr(％): 19.5~23.5
Ni(％): 38~46

Mo(%): 2.5~3.5

Cu(%): 0.5~3.0

Ti(%): 0.6~1.2

Co(%): --

Al(%): ≤0.2

Fe(%): ≥22.0

C(％): ≤0.05
Si(％): ≤0.5
Mn(％): ≤1.0
P(％)≤: 0.03
S(％)≤: 0.015
Cr(％): 19.5~23.5
Ni(％): 38~46

Mo(%): 2.5~3.5

Cu(%): 1.5~3.0

Ti(%): 0.6~1.2

Co(%): --

Al(%): ≤0.2

Fe(%): Remainder


W-Nr 2.4858 NiCr21Mo Steel Forging Piece N08825 Incoloy 825 Bar

NiCr21Mo W-Nr 2.4858 Mechanical Properties

Tensile strength, σb/Mpa: ≥590

Yield Point, σs/Mpa: ≥220

Elongation, δ/%: ≥30

Reduction of Area,ψ/%: --

Hardness (HB): --

Applications

NiCr21Mo W-Nr 2.4858 is commonly used in chemical processing, nuclear fuel reprocessing, acid production, pickling equipment and other industries.
