X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate
X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate
X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate
X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate
X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate
X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
X5CrNiMoCuNb14-5, W-Nr1.4594, FV520B
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
800kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion-Resistant
Heat treatment condition :
+QT, +AT, etc
Processing methods :
Milled, Cold working, etc
Available Shapes :
Square bar, Strip steel, Wire, etc
Surface :
Rrough Turned, Grinded, etc
Material Category :
Martensitic creep resistant steel
Description

X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate

Production Information

1.4906 stainless steel is a corrosion-resistant and creep-resistant steel, which is widely used in turbine blades and boiler equipment as well as in the chemical industry

Size Range

Round bar / Wire rod (Diameter):

3.0 mm to 500 mm

Square bar / Flat bar:

3.0 mm to 500 mm

Forging piece:

Stepped shafts with flanks/discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled:

T5.5 - 100 mm X W5 - 1000 mm X L1000-10000 mm

Sheet steel via cold rolled:

T0.3 - 10.0 mm X W5 - 800 mm X L1000 - 10000 mm

Steel strip via cold rolled:

T0.1 - 10.0 mm X W5 - 1000 mm X L (or in coil form)

Length:

Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

X12CrMoWVNbN10-1-1/1.4906
--

C(％): 0.11~0.13
Si(％): ≤0.12
Mn(％): 0.40~0.55
P(％)≤: 0.01
S(％)≤: 0.005
Cr(％): 10.0~10.6
Ni(％): 0.70~0.80
Mo(％): 1.0~1.5

W(%): 0.95~1.05

N(%): 0.04~0.07

Nb(％): 0.04~0.08

V(％): 0.15~0.25

Al(％): ≤0.01

X12CRMOWVNBN10-1-1 W-NR 1.4906 Stainless Steel JIS9CRW KT 5330 Plate

Mechanical Properties


X5CrNiMoCuNb14-5 / 1.4594 Alloy Steel Plates Mechanical Properties

Heat Treatment: solution annealed + aged

Tensile strength,Rm/MPa: 870~970

Yield strength,Rp/MPa: ≥750

Elongation/%: ≥14

Hardness/HB: 270~310

Application

  • Turbine blades
  • Turbine and Boiler manufacturing
  • screws, nuts
  • fittings and other components in chemical
  • reactor engineering
