UNS S30530 Alloy Steel Hot Rolled Flat Bar
UNS S30530 Alloy Steel Hot Rolled Flat Bar
UNS S30530 Alloy Steel Hot Rolled Flat Bar
UNS S30530 Alloy Steel Hot Rolled Flat Bar
UNS S30530 Alloy Steel Hot Rolled Flat Bar
UNS S30530 Alloy Steel Hot Rolled Flat Bar
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
UNS S30530
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
800kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
UNS S30530 Alloy Steel Hot Rolled Flat Bar
Characteristic :
Corrosion and Heat Resistant
Heat treatment condition :
+AT, +P, etc
Processing methods :
Ground, Cold working, etc
Available Shapes :
Sheet steel via cold rolled, Steel strip via cold rolled, etc
Surface :
Polished, Black, etc
Description

UNS S30530 Alloy Steel Hot Rolled Flat Bar

Product Information

UNS S30530 is a high-temperature corrosion-resistant alloy, also known as Avesta 253MA or Outlookumpu 253MA. It is an austenitic stainless steel with high oxidation resistance and corrosion resistance, and can be used in high-temperature environments up to 1150 ° C.
UNS S30530 alloy has excellent processability and weldability, and can be manufactured using conventional processing and welding methods. It is also a low magnetic alloy suitable for certain applications that require low magnetism.
In summary, UNS S30530 alloy has excellent corrosion resistance, high-temperature performance, and processing performance, making it a high-performance alloy widely used in high-temperature applications.


Size Range

Round bar / Wire rod (Diameter):1.0 mm to 1000 mm
Square bar / Flat bar: 5.0 mm to 800 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5.0 - 1500 mm X W5 - 1000 mm X L100-1000 mm
Sheet steel via cold rolled: T1.0 - 10 mm X W1 - 1000 mm X L100 - 1000 mm
Steel strip via cold rolled: T1.0 - 10 mm X W1.0 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

AISI 429/S42900

 Mechanical Properties

ASTM A 959-2004

C(％): ≤0.08
Si(％): 0.50~2.50
Mn(％): ≤2.00
P(％)≤: 0.045
S(％)≤: 0.03

Cr(％): 17.0~20.5
Ni(％): 8.50~11.5
Mo(%): 0.75~1.50

Cu(%): 0.75~3.50

Tensile strength,Rm/MPa: ≥515
Yield strength,Rp/MPa: ≥205

Elongation, A/%: ≥40

Reduction of area, ψ/%: -

Impact, KV /J: -

Hardness HRC: ≤201

UNS S30530 Alloy Steel Hot Rolled Flat Bar

Applications

UNS S30530 alloy is suitable for many high-temperature applications, such as boilers, heat exchangers, furnaces, burners, and furnace tubes.


If you are interested in our products or have any questions, please contact our team of engineers at
sales@ss-bars.com

UNS S30530 Alloy Steel Hot Rolled Flat BarUNS S30530 Alloy Steel Hot Rolled Flat Bar


UNS S30530 Alloy Steel Hot Rolled Flat Bar
