Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
ASTM XM-16, Custom 455, UNS S45500
Certification :
SGS,TUV,BV,ISO,MTC
Place of Origin :
China
MOQ :
Negotiations
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
70000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 45-55days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
XM-16 Stainless Steel Sheets Plates
Grades :
ASTM XM-16, Custom 455, UNS S45500
Processing methods :
Cold working,Ground,Peeled,etc
Surface :
Bright,Centreless Ground,Rrough Turned,etc
Profile :
Round Bar,Forging Parts,Flat Bar,Sheets Plates,etc
Price Term :
Ex-work,CIF,FOB,DDU,CFR,etc.
Description

XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates


Description


XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates is a martensitic precipitation steel, based on fine structure, with high corrosion resistance and high tenacity.XM-16 Stainless Steel Sheets Plates is soft martensitic fine steel due to it's low carbon content. The highest hardness of apprx. 49 HRC can be achieved at condition H900. The high hardness enhances the wear resistance and deformation resistance
All of XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates conform to Military standard, nuclear power. 100% Ultrasonic test SEP 1923 /GB/T 4162 /ASTM E2375 /SAE AMS 2154 /EN 10228-3.

  • Shape:Stainless Steel Sheets Plates
  • Material:Metal,XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates
  • Length: Fixed length or random length or based on the customer's special requirement.
  • Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm

  • Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm

  • Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)



Products Details


XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates

Chemical Composition

(weight%):

Mechanical Properties Under

Final Heat Treatment:

C (%): ≤ 0.05
Si (%): ≤ 0.50
Mn (%): ≤ 0.50
P (%)≤: 0.040
S (%)≤: 0.030
Cr (%): 11.0 ~ 12.5
Ni (%): 7.50 ~ 9.50
Mo (%): ≤ 0.50
Ti (%): 0.80 ~ 1.40
Cu (%): 1.25 ~ 2.50
(Nb+Ta) (%): 0.15 ~ 0.50
Forms: round bar, steel plate, strip
Condition: solution treatment
Tensile strength, σb/MPa: 1205
Yield strength, σ0.2/MPa: 1105
Elongation, δ(%): 3.0
Reduction of area, ф(%): 36
Hardness | HRW: 361min, HRC 36min.


Applications:


XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates used most often in the Heat Exchangers, Surface Condensers,

Conveyors, Food Processing, etc.


XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets PlatesXM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates

XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates


FAQ

Q: How do you control the quality?


A: We have professional inspectors to analyze the chemical composition of XM-16 Stainless Steel Sheets Plates Custom 455 UNS S45500 Sheets Plates and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, set length, bending, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1000KG.If you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, We will have more stable and long-term cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, FedEx/DHL/UPS accounts can be used for sampling, and the transportation cost is borne by you.
