DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar Treated
DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar Treated
DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar Treated
DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar Treated
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
DIN EN X2CrNiN18-10,1.4311
Certification :
SGS,TUV,BV,ISO,MTC
Place of Origin :
China
MOQ :
Negotiations
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
30000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 50-60days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
DIN EN X2CrNiN18-10,1.4311 Stainless Steel Flat Bar
Grades :
DIN EN X2CrNiN18-10,1.4311
Processing methods :
Cold working,Machined,Peeled,etc
Surface :
Grinding Centreless Ground,Rrough Turned,etc
Profile :
Sheets Plates,Forging Parts,etc
Price Term :
Ex-work,FOB,CIF,etc
Description

DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar X2CrNiN18-10 Flat Bar 1.4311 Bar

Description

Our company provides DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar.

All of DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

  • Material:Metal,Stainless Steel Flat Bar,DIN EN X2CrNiN18-10 1.4311.
  • Shape:Stainless Steel Flat Bar.
  • Square bar / Flat bar: 3mm to 800mm

Products Details

DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar

Chemical Composition (weight%): C (％): ≤ 0.030
Si (％): ≤ 1.00
Mn (％): ≤ 2.00
P (％): ≤ 0.045
S (％)≤: 0.015
Cr (％): 17~19.5
Ni (％): 8.50~11.5
Mo (％): -
N (％): 0.12 ~ 0.22
Mechanical Properties Under
Final Heat Treatment:		 Hot working temperature /℃: 1150～750
Heat treatment temperature /℃|annealing / normalizing : -
Heat treatment temperature /℃|quenching: 1050 -110 water/ Air
Heat treatment temperature /℃|tempering: -
Normal temperature and low temperature | Condition: Room temperature
(≥)|σb/MPa: 540～740
(≥)|σs/MPa: -
(≥)|δ5(%): 40
(≥)|ψ(％)≥: 50
(≥)|AKV(DVM)/J: 100
Normal temperature and low temperature | Condition: -80℃
(≥)|σb/MPa: 780
(≥)|σs/MPa: -
(≥)|δ5(%): 35
(≥)|ψ(％)≥: -
(≥)|AKV(DVM)/J: 96

DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar Treated

Applications:

DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar

Alloy structural steels are widely used in the filed of ship, vehicle, airplane, guided missile, weapons, railway, bridges, pressure vessel, machine tools, mechanical components with a bigger sectional size and so on.
Mechanical gears, gear shaft, main axis, valve rod
Mechanical parts - connecting rod, bolt and nut
Multidiameter shaft
Pressure vessel, seamless pipe

Equivalent Grade

DIN EN X2CrNiN18-10 DIN EN 10088-1 2014

1.4311

DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar TreatedDIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar Treated

DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar

FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one.


Q: Do you accept customization?

A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1000 kg. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, UPS/DHL/FedEx accounts can be used for sampling, and the courier fee is borne by you.

DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar Treated
