MachineU > China Products > Minerals & Metallurgy > Carbon Steel > Long Steel Products > Steel Round Bars
Machined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat Bar
Machined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat Bar
Machined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat Bar
Machined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat Bar
Specifications
Brand Name :
ANSTEEL,TISCO,BAOSTEEL,PANGANGGROUP
Model Number :
ASTM 405,UNS S40500
Certification :
SGS,TUV,BV,ISO,MTC
Place of Origin :
China
MOQ :
900kg or Negotiations
Price :
2000-3000 USD/Ton or Negotiations
Payment Terms :
T/T
Supply Ability :
100000KGS/Month
Delivery Time :
Ex-stock for delivery: 6-8 days Production lead time: 42-45 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product name :
ASTM 405 UNS S40500 Turbine Blade Steel
Executive Technical Standard :
ASTM,UNS etc.
Grades :
ASTM 405,UNS S40500
Processing methods :
Cold working,Machined etc.
Heat treatment condition :
Q+T etc.
Surface :
Black,Bright,Rrough Turned,Grinding etc.
Profile :
Rod Bar,Flat Bar etc.
Price Term :
Ex-work, FOB, CIF etc.
Description

ASTM 405 UNS S40500 Turbine Blade Steel ASTM 405 Round Bar UNS S40500 Flat Bar


Description

Our company provides ASTM 405 UNS S40500 Hot Rolled Turbine Blade Steel ASTM 405 Cold Drawn Round Bar UNS S40500 Flat Bar.
All of ASTM 405 UNS S40500 Hot Rolled Turbine Blade Steel ASTM 405 Cold Drawn Round Bar UNS S40500 Flat Bar. conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

  • Shape:Turbine Blade Steel.
  • Round bar / Wire rod (Diameter): 5.5mm to 800mm
  • Square bar / Flat bar: 3mm to 800mm
  • ASTM 405 UNS S40500 Hot Rolled Turbine Blade Steel ASTM 405 Cold Drawn Round Bar UNS S40500 Flat Bar.Length: Fixed length or random length or based on the customer's special requirement.


Products Details


ASTM 405 UNS S40500 Hot Rolled Turbine Blade Steel ASTM 405 Cold Drawn Round Bar UNS S40500 Flat Bar.
The alloy is usually produced by BEF + AOD / EAF + VD + LF followed by electroslag refining (ESR) / VAR if necessary for special purpose.

Chemical Composition (weight%):

C (％): ≤ 0.08

Si (％): ≤ 1.00
Mn (％): ≤ 1.00
P (％)≤: 0.040
S (％)≤: 0.030
Cr (％): 11.0 - 14.50
Ni (％): ≤ 0.50
Mo (％): -
Al (％): 0.10 - 0.30

Mechanical Properties Under
Final Heat Treatment:

Condition: annealing
Tensile strength, σb/MPa: 415
Yield strength, σ0.2/MPa: 170
Elongation, δ(％): 20.0
Reduction of area, ф(％): -
Hardness | HBW: 179
Hardness | HRB: 88
Cold bending property: N


Machined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat Bar
Applications:
ASTM 405 UNS S40500 Hot Rolled Turbine Blade Steel ASTM 405 Cold Drawn Round Bar UNS S40500 Flat Bar.Chemical equipment,Mechanical parts used in the condition of corrosion resistance,Bolt and nut,Pressure vessel

Technical Standard
ISO/TS 15510(2003)
JIS G4303(2005)
KS D3706(2006)
IS 6527(2001)
DIN EN 10088-1(2005)
NF EN 10088-2(2005)
NF A35-573(1984)
BS 970-1(1996)
ASTM A959(2004)
Equivalent Grade
SUS 405
STS 405
X04Cr13
X6Cr13/1.4000
Z6CA13
403S17
405/S40500


Machined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat BarMachined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat Bar
ASTM 405 UNS S40500 Hot Rolled Turbine Blade Steel ASTM 405 Cold Drawn Round Bar UNS S40500 Flat Bar.

FAQ


Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of ASTM 405 UNS S40500 Turbine Blade Steel ASTM 405 Round Bar UNS S40500 Flat Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.

Machined Steel Turbine Blade ASTM 405 Round Bar UNS S40500 Flat Bar
