SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410
SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410
SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410
SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410
Specifications
Brand Name :
ANSTEEL,TISCO,BAOSTEEL,PANGANGGROUP
Model Number :
ASTM 410,AMS 5504,AMS 5505,UNS S41000,AISI 410,DIN 1.4006
Certification :
SGS,TUV,BV,ISO,MTC
Place of Origin :
China
MOQ :
600kg or Negotiations
Price :
2200-3300 USD/Ton or Negotiations
Payment Terms :
T/T
Supply Ability :
200000KGS/Month
Delivery Time :
Ex-stock for delivery: 4-8 days Production lead time: 45-55 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name :
ASTM 410 Turbine Blade Steel
Executive Technical Standard :
ASTM,AISI,AMS,UNS,DIN etc.
Grades :
ASTM 410,AMS 5504,AMS 5505,UNS S41000,AISI 410,DIN 1.4006
Processing methods :
Peeled,Milled,Cold working etc.
Heat treatment condition :
Q+T etc.
Surface :
Bright,etc.
Profile :
Round Bar,Flat Bar etc.
Price Term :
Ex-work, FOB, CIF, CFR, DDU etc.
Description

ASTM 410 Turbine Blade Steel AISI 410 AMS 5504 Round Bar S41000 Flat Bar 1.4006 Bar

Description

Our company provides ASTM 410 Turbine Blade Steel AMS 5504-5505 Round Bar UNS S41000 Flat Bar 1.4006 Bar ASTM A959-2004.

All of ASTM 410 Turbine Blade Steel AMS 5504-5505 Round Bar UNS S41000 Flat Bar 1.4006 Bar ASTM A959-2004 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

  • Material:Metal,Turbine Blade Steel,ASTM 410,AMS 5504/5505,UNS S41000,AISI 410,DIN 1.4006.
  • Shape:Turbine Blade Steel.
  • Round bar / Wire rod (Diameter): 5.5mm to 800mm
  • Square bar / Flat bar: 3mm to 800mm

​

Products Details

ASTM 410,AMS 5504/5505,UNS S41000,AISI 410,DIN 1.4006

The alloy is usually produced by BEF + AOD / EAF, followed by electroslag refining (ESR or VAR ) if necessary for special purpose.

Chemical Composition (weight%): Mechanical Properties Under Final Heat Treatment:
C (％): ≤ 0.08
Si (％): ≤ 1.00
Mn (％): ≤ 1.00
P (％)≤: 0.040
S (％)≤: 0.030
Cr (％): 11.0 - 14.50
Ni (％): ≤ 0.50
Mo (％): -
Al (％): 0.10 - 0.30		 Condition: annealing
Tensile strength, σb/MPa: 415
Yield strength, σ0.2/MPa: 170
Elongation, δ(％): 20.0
Reduction of area, ф(％): -
Hardness | HBW: 179
Hardness | HRB: 88
Cold bending property: N

SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410

This specification covers Stainless steel forgings for compressor and turbine bucket, blade, and airfoil applications

Technical Standard Equivalent Grade
ISO/TS 15510(2003) X12Cr13
JIS G4303(2005) SUS 410
KS D3706(2006) STS 410
IS 6528(2001) X12Cr13
DIN EN 10088-2(2005) X12Cr13/1.4006
NF EN 10088-2(2005) X12Cr13
BS EN 10088-2(2005) X12Cr13
BS 970-1(1996) 410S21
ASTM A959(2004) 410/S41000

SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410

SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410

FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.

SGS Certified Steel Rod Bar AISI 410 AMS 5504 ASTM 410
