AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip
AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip
AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip
AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip
AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip
AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5630, UNS S44004, AISI 440C, UNS 5630L
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
800kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
45000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion Resistance
Heat treatment condition :
+A, +N, etc.
Processing methods :
Ground, Peeled, etc
Available Shapes :
Bars, Wire, Forgings...
Surface :
Grinding, Centreless Ground, etc.
Application :
Vanes, Shafts, Blades, Dowels,
Material Category :
Martensitic stainless steel
Description

AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip

Size Range

Round bar / Wire rod (Diameter): 3.5mm to 1000mm
Square bar / Flat bar: 5.0mm to 1000mm
Forging piece:

Stepped shafts with flanks / discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5 - 250mm X W10 - 1500mm X L1000-11000mm

Sheet steel via cold rolled:

T0.5 - 4mm X W6 - 1000mm X L1000 - 1000mm

Steel strip via cold rolled:

T0.3 - 3.0mm X W5 - 180mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5630L

 UNS S44004/AISI 440C
standard SAE AMS 5630L-2013 ASTM A493-2009(2013)
Chemical Composition (weight%)

C(％): 0.95~1.20
Si(％): ≤1.0
Mn(％): ≤1.0
P(％)≤: 0.040
S(％)≤: 0.030
Cr(％): 16.0~18.0
Ni(％): ≤0.75
Mo(％): 0.40~0.65

Cu(％): ≤0.50

C(％): 0.95~1.20
Si(％): ≤1.0
Mn(％): ≤1.0
P(％)≤: 0.040
S(％)≤: 0.030
Cr(％): 16.0~18.0
Ni(％): --
Mo(％): ≤0.75

Cu(％): --


AMS 5630 Stainless Steel Flat Bar UNS S44004 Cold Rolled Strip


Mechanical Properties


AMS 5630 Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa: --
Yield strength,Rp/MPa: --
Elongation/%: --
Reduction of area, ψ/%: --
Impact, KV /J: --
Annealed hardness HBS: ≤ 255
