AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats
AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats
AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats
AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats
AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats
AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5510E, UNS S30400, AMS 5510
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
1100kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
40000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Oxidation resistance, Corrosion resistance, Profit
Heat treatment condition :
+NT, +A, +N, etc.
Processing methods :
Peeled, Milled, Machined, etc
Available Shapes :
middle plate via hot rolled, Round bar, Flat bar, etc
Surface :
Rrough Turned, peeled + polishing, etc.
Application :
Nuts, Gears, Pinion Spindles, etc
Material Category :
Austenitic Stainless Steel
Description

AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats


Product introduction

High chromium nickel austenitic stainless steel has excellent corrosion resistance in oxidizing medium and high temperature mechanical properties. Its oxidation resistance is better than 309 stainless steel, and its pitting corrosion resistance and stress corrosion resistance are better than 18-8 stainless steel. It can be used as both corrosion resistant parts and heat resistant steel. Can withstand repeated heating below 1035 ° C

Size Range

Round bar / Wire rod (Diameter): 3.0mm to 900mm
Square bar / Flat bar: 3.5mm to 1200mm
Forging piece:

Stepped shafts with flanks / discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 150mm X W10 - 1300mm X L1000-8000mm

Sheet steel via cold rolled:

T0.3 - 5mm X W6 - 1000mm X L1000 - 1000mm

Steel strip via cold rolled:

T0.1 - 4.50mm X W5 - 150mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5651J
standard SAE AMS 5651J-2003
Chemical Composition (weight%)
C (％): ≤ 0.08
Mn (％): ≤ 2.00
Si (％): 0.3~0.8
P (％)≤: 0.040
S (％)≤: 0.030
Cr (％): 24.0~26.0
Ni (％): 19.0~22.0
Mo (%): ≤ 0.75
Cu (%): ≤ 0.75
Fe (%): Remainder.


AMS 5651J Stainless Steel UNS S31008 Cold Drawn Flats


Mechanical Properties


AMS 5651J Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa: 515
Yield strength,Rp/MPa: 205
Elongation/%: 40
Reduction of area, ψ/%: --
Impact, KV /J: --
Annealed hardness HBS: ≤187
