AMS 5657 Stainless Steel Flat Bar Grinding
AMS 5657 Stainless Steel Flat Bar Grinding
AMS 5657 Stainless Steel Flat Bar Grinding
AMS 5657 Stainless Steel Flat Bar Grinding
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5657, PH 15-7Mo, AISI 632, UNS S15700
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
1000kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
40000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Forgeability, Corrosion Resistant
Heat treatment condition :
+A, +N, +QT, +P, etc.
Processing methods :
Ground,Peeled, Milled, etc
Available Shapes :
Flat bar, Length, Heavy, etc
Surface :
Rrough Turned, Grinding, Centreless Ground, etc.
Application :
Pressure Vessels, Valves, Flanges...
Material Category :
Aerospace Material Steel Series
Description

AMS 5657 Stainless Steel Flat Bar

Size Range

Round bar / Wire rod (Diameter): 4.0mm to 900mm
Square bar / Flat bar: 3.0mm to 1100mm
Forging piece:

Stepped shafts with flanks / discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 100mm X W10 - 1300mm X L1000-10000mm

Sheet steel via cold rolled:

T0.5 - 5mm X W6 - 1000mm X L1000 - 11000mm

Steel strip via cold rolled:

T0.1 - 3.0mm X W5 - 150mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5657
standard --
Chemical Composition (weight%)
C (％): ≤ 0.09
Mn (％): ≤ 1.00
Si (％): ≤ 1.00
P (％)≤: 0.035
S (％)≤: 0.020
Cr (％): 16.0 ~ 18.0
Ni (％): 6.50 ~ 7.70
Al (%): 0.75 ~ 1.50
Mo (%): 2.00 ~ 3.00
Fe (%): Remainder.


AMS 5657 Stainless Steel Flat Bar Grinding


Mechanical Properties


AMS 5657 Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa: ≥1240
Yield strength,Rp/MPa: ≥1100
Elongation/%:

≥8
Reduction of area, ψ/%:

≥25
Impact, KV /J: --
Annealed hardness HBS: ≤355
