AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel
AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel
AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel
AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel
AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel
AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
AMS 5504, UNS S41000
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
1000kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
45000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion and Heat-Resistant
Heat treatment condition :
+N, +NT, etc.
Processing methods :
Milled, Cold working. etc
Available Shapes :
Sheet, Strip,and Plate...
Surface :
peeled + polishing, etc.
Application :
Turbine blades, bolts, hydraulic valves
Material Category :
Martensitic stainless steel
Description

AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel


Describe

AMS 5504 stainless steel is a general-purpose martensitic stainless steel containing 11.5% chromium with good corrosion resistance. However, through a series of processes such as quenching, tempering, and polishing, the corrosion resistance of AMS 5504 steel can be further enhanced. Quenching and tempering can harden AMS 5504 steel. They are typically used in applications involving mild corrosion, heat resistance and high strength.

Martensitic stainless steels are manufactured using techniques that require a final heat treatment. These grades have poor corrosion resistance compared to austenitic grades. Their operating temperature is often affected by loss of strength at elevated temperatures due to overtempering and loss of ductility at sub-zero temperatures.

Size Range

Round bar / Wire rod (Diameter): 3.5mm to 900mm
Square bar / Flat bar: 3.0mm to 1000mm
Forging piece:

Stepped shafts with flanks / discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 350mm X W10 - 1500mm X L1000-12000mm

Sheet steel via cold rolled:

T0.5 - 5mm X W6 - 1000mm X L1000 - 1100mm

Steel strip via cold rolled:

T0.1 - 4.0mm X W5 - 190mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5504
standard SAE AMS 5504M-2012
Chemical Composition (weight%)

C(％): ≤0.15 Cu(％): ≤0.50
Si(％): ≤1.0 Al(％): ≤0.05
Mn(％): ≤1.0 Sn(%): ≤0.05
P(％)≤: 0.04 N(%): ≤0.08
S(％)≤: 0.03
Cr(％): 11.5~13.5
Ni(％): ≤0.75
Mo(％): ≤0.50


AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel


Mechanical Properties


AMS 5504 Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa: 448~655
Yield strength,Rp/MPa: ≥207
Elongation/%: 12~15
Reduction of area, ψ/%: --
Impact, KV /J: --
Annealed hardness HB: --
