W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel
W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel
W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel
W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel
W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel
W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
W-Nr 1.4312, JIS SCS 12, 10KH18N9L, ASTM A743 CF20, UNS J92602
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
800kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
50000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion Resistant
Heat treatment condition :
+P, +AT,+QT, etc.
Processing methods :
Cold working, Hot Working, etc
Available Shapes :
Length, Heavy, middle plate via hot rolled, Sheet steel via cold rolled,
Surface :
Rrough Turned, Grinded
Material Category :
Stainless cast steel
Description

W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel

Product Information

Structural Steel 1.4312 is commonly used corrosion-resistant cast steel.

Size Range

Round bar / Wire rod (Diameter):

10.0 mm to 1000 mm

Square bar / Flat bar:

3.0 mm to 1000 mm

Forging piece:

Stepped shafts with flanks/discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled:

T5 - 200 mm X W5 - 1000 mm X L1000-10000 mm

Sheet steel via cold rolled:

T0.5 - 10.0 mm X W5 - 1000 mm X L1000 - 10000 mm

Steel strip via cold rolled:

T0.3 - 10.0 mm X W5 - 1000 mm X L (or in coil form)

Length:

Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

W-Nr 1.4312

 CF20/UNS J92602

SCS 12
-- ASTM A743/A743M-21

JIS G 5121-2003

C(％): ≤0.12
Si(％): ≤2.0
Mn(％): ≤1.50
P(％)≤: 0.045
S(％)≤: 0.030
Cr(％): 17.0~19.5
Ni(％): 8.0~10.0
Mo(％): --

 C(％): ≤0.2
Si(％): ≤1.50
Mn(％): ≤2.0
P(％)≤: 0.040
S(％)≤: 0.040
Cr(％): 18.0~21.0
Ni(％): 8.0~11.0
Mo(％): --

C(％): ≤0.2
Si(％): ≤2.0
Mn(％): ≤2.0
P(％)≤: 0.040
S(％)≤: 0.040
Cr(％): 18.0~21.0
Ni(％): 8.0~11.0
Mo(％): --


W-Nr 1.4312 Structural Steel Flat Bar SCS 12 Mould Steel

Mechanical Properties


1.4312 Structural Steel Flat Bar Mechanical Properties

Tensile strength, Rm/MPa: 650~880
Yield strength, Rp/MPa: 350~550
Elongation, A/%: 8~25
Reduction of area, ψ/%: --
Impact, AKV /J: --
Annealed hardness HBW: --

Application

Plastic molds, High-gloss plastic molds, Press plates, Drop hammer mold bases and sliders, Forging molds and various plastic product molds.
