DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips
DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips
DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips
DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips
DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips
DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips
Specifications
Brand Name :
PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number :
X5CrNiCuNb17-4-4, W-Nr 1.4548, 10705 GU-GV, TLV 9239 01
Certification :
SGS, TUV, BV, ISO, MTC
Place of Origin :
China
MOQ :
1500kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
45000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic :
Corrosion-Resistant
Heat treatment condition :
+AT +QT, etc
Processing methods :
Machined Peeled, etc
Available Shapes :
Sheet, Strip steel, etc
Surface :
Peeled, Black, etc
Material Category :
Precipitation Hardening Chrome-Nickel-Copper Stainless Steel
Description

DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips

Production Information

1.4548 is a stainless steel with a high yield point, high wear resistance and good corrosion resistance. This material is currently stored in conditions H1150 and H1025. It can also be used in the low temperature range! Excellent notched impact strength even at sub-zero temperatures!

Size Range

Round bar / Wire rod (Diameter):

5.0 mm to 500 mm

Square bar / Flat bar:

3.5 mm to 300 mm

Forging piece:

Stepped shafts with flanks/discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled:

T5.5 - 100 mm X W5 - 1000 mm X L1000-10000 mm

Sheet steel via cold rolled:

T0.5 - 10.0 mm X W5 - 1000 mm X L1000 - 10000 mm

Steel strip via cold rolled:

T0.5 - 5.0 mm X W10 - 1000 mm X L (or in coil form)

Length:

Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

X5CrNiCuNb17-4-4 / 1.4548
--

C(％): ≤0.07
Si(％): ≤1.00
Mn(％): ≤1.00
P(％)≤: 0.025
S(％)≤: 0.025
Cr(％): 15.0~17.5
Ni(％): 3.0~5.0
Mo(％): --

Cu(%): 3.0~5.0

Nb(%): 0.15~0.45

DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips

Mechanical Properties


X5CrNiCuNb17-4-4 / 1.4548 Stainless Steel Flat Bar Mechanical Properties

Condition: H1025

Tensile strength,Rm/MPa: ≥1000

Yield strength,Rp/MPa: ≥1070

Elongation/%: ≥11

Application

  • Chemical industry
  • Wood industry
  • Offshore
  • Shipbuilding
  • Mechanical engineering
  • Aerospace
Contact us

Looking forward to your cooperation, please let us provide you with better service, please contact us.

DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV StripsDIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips





DIN 1.4548 X5CrNiCuNb17-4-4 Stainless Steel Flat Bar 10705 GU-GV Strips
