DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622
DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622
DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622
DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622
Specifications
Brand Name :
PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL
Model Number :
DIN EN 14Ni6, W-Nr 1.5622
Certification :
SGS,TUV,BV,ISO,MTC
Place of Origin :
China
MOQ :
500kg or Negotiations
Price :
3000-5000 USD/Ton or Negotiations
Payment Terms :
T/T
Supply Ability :
95000KGS/Month
Delivery Time :
Ex-stock for delivery: 5-9 days Production lead time: 40-45 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product name :
DIN EN 14Ni6 Structural Steel Round Bar
Grades :
DIN EN 14Ni6, W-Nr 1.5622
Processing methods :
Ground,Peeled,Milled,Cold working,Machined etc.
Heat treatment condition :
Solution treated,Quenched and tempered etc.
Surface :
Bright,Rrough Turned,Grinding,Centreless Ground etc.
Profile :
Flat Bar,Forging Parts,Sheets Plates etc.
Price Term :
Ex-work, FOB, CIF, CFR, DDU etc.
Description

DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622


Description


DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622 is a low-temperature structural steel with a tensile strength of 490 – 640 N/mm². Like all low-temperature steels, this material has sufficient impact strength at low temperatures. DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622 is often used in the chemical industry and in refrigeration technology.
All of DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

  • Material:Metal,Structural Steel Round Bar,DIN EN 14Ni6 W-Nr 1.5622
  • Shape:Structural Steel Round Bar
  • Round bar / Wire rod (Diameter): 5.5mm to 800mm
  • Square bar / Flat bar: 3mm to 800mm
  • Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
  • Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
  • Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
  • Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
  • Length: Fixed length or random length or based on the customer's special requirement.


Products Details

DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622

Chemical Composition (weight%): Mechanical Properties Under Final Heat Treatment:
C (％): ≤ 0.18
Si (％): 0.10 ~ 0.35
Mn (％): 0.30 ~ 0.60
P (％)≤: 0.035
S (％)≤: 0.035
Cr (％): -
Ni (％): 1.30 ~ 1.60
V (％): -		 Hot working temperature /℃: 1100～850
Heat treatment temperature /℃|annealing / normalizing : 860~890
Heat treatment temperature /℃|quenching: 860~890 water, oil, air
Heat treatment temperature /℃|tempering: 600~670
Normal temperature and low temperature | Condition: room temperature
Tensile strength, (≥)|σb/MPa: 490～640
Yield strength, (≥)|σs/MPa: 275
Elongation, (≥)|δ5(%): 20
Reduction of area, |ψ(％)≥: 60
Impact strength, (≥)|AKv (DVM)/J: 103

DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622


Applications:


DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622 is often used in the chemical industry and in refrigeration technology.

Technical Standard Equivalent Grade
ISO/TS 15510(2003) X6Cr13
JIS G4303(2005) SUS 405
KS D3706(2006) STS 405
IS 6527(2001) X04Cr13
DIN EN 10088-1(2005)

X6Cr13/1.4000
NF EN 10088-2(2005) X6Cr13
NF A35-573(1984) Z6CA13
BS 970-1(1996) 403S17
ASTM A959(2004) 405/S40500


DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622DIN EN 14Ni6 Structural Steel Round Bar W-Nr 1.5622


FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
