AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate
AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate
AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate
AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate
AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate
AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate
Specifications
Brand Name :
PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL
Model Number :
AISI P20+S, 40CrMnMoS 8-6, W-Nr 1.2312
Certification :
SGS,TUV,BV,ISO,MTC
Place of Origin :
China
MOQ :
1000kg
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
45000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product name :
AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate
Grades :
AISI P20+S, 40CrMnMoS 8-6, W-Nr 1.2312
Processing methods :
Ground,Peeled, Milled, Cold working, Machined, etc.
Heat treatment condition :
Annealed, Solution Treated, Quenched And Tempered,etc
Surface :
Rrough Turned, Grinding, Centreless Ground, etc
Available Shapes :
Square bar, Flat bar, Length, Heavy, middle plate via hot rolled, Sheet steel via cold rolled, Steel strip via cold rolled, Forging piece,etc
Price Term :
Ex-work, FOB, CIF, CFR, DDU etc.
Description

AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate

Describe

P20+S plastic mold steel, due to high content of S, has excellent machinability, good toughness, good wear resistance, uniform hardness of each size, stable size, no heat treatment, 280-325HB quenched and tempered state, suitable for nitriding treatment Increase wear resistance, not suitable for chrome plating, polishing and etch graining.

  • Material:Metal, Structural Steel Round Bar, P20+S Tool Steel Round Bar
  • Shape:Tool Steel
  • Round bar / Wire rod (Diameter): 5.5mm to 800mm
  • Square bar / Flat bar: 3mm to 800mm
  • Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
  • Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
  • Length: Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade 40CrMnMoS 8-6 W-Nr 1.2312 AISI P20+S
standard DIN 17350-1980 ASTM A681
Chemical Composition (weight%)

C(％): 0.35~0.45
Si(％): 0.3~0.5

Mn(％): 1.4~1.6
P(％)≤: 0.03
S(％): 0.05~0.1
Cr(％): 1.8~2.0

Ni(％): - -
Mo(％): 0.15~0.25

C(％): 0.28~0.40

Si(％): 0.60~1.00

Mn(％): ≤0.03
P(％)≤: 0.03

S(％)≤: 0.2~0.8
Cr(％): 1.4~2.0

Ni(％): - -
Mo(％): 0.30~0.55
Other - - - - - -

AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate

Mechanical Properties

40CrMnMoS 8-6/1.2312 Tool Steel Mechanical Properties

Tensile strength,Rm/MPa: ≥960
Yield strength,Rp/MPa: ≥850
Elongation/%: ≥10
Reduction of area, ψ/%: ≥45

Applications

40CrMnMoS 8-6/1.2312 Tool Steel is often used For making plastic processing tools, mold frames...


AISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 PlateAISI P20+S Tool Steel 40CrMnMoS 8-6 W-Nr 1.2312 Plate


FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
