AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200
AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200
AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200
AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200
Specifications
Brand Name :
PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL
Model Number :
AMS 5655, ASTM 422, UNS S42200
Certification :
SGS,TUV,BV,ISO,MTC
Place of Origin :
China
MOQ :
Negotiations
Price :
Negotiations
Payment Terms :
T/T
Supply Ability :
55000KGS/Month
Delivery Time :
Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details :
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product name :
AMS 5655 Turbine Blade Steel
Grades :
AMS 5655, ASTM 422, UNS S42200
Processing methods :
Ground,Peeled, Milled, etc.
Heat treatment condition :
Quenched And Tempered,etc
Surface :
Grinding, Centreless Ground, etc
Available Shapes :
Round bar, Flat bar, Length, Forging piece,etc
Price Term :
Ex-work, FOB, CIF, CFR, DDU etc.
Description

AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200


Description

AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200 is characterized by martensitic crystal structure, which gives AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200 good mechanical properties, such as excellent creep-rupture and resistance to scaling at temperatures up to 649° C.

All of AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

  • Material:Metal, Turbine Blade Steel, AMS 5655 Turbine Blade Steel
  • Shape:Turbine Blade Steel
  • Round bar / Wire rod (Diameter): 5.5mm to 800mm
  • Square bar / Flat bar: 3mm to 800mm
  • Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
  • Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
  • Length: Fixed length or random length or based on the customer's special requirement.


Products Details

AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200

Chemical Composition (weight%): Mechanical Properties Under Final Heat Treatment:
C(％): 0.45
Si(％): 0.65
Mn(％): 0.55
Cr(％): 12.5
Ni(％): —
Mo(％): 0.55
Co(％): —
W(％): —
Al(％): —
Cu(％): —
Ti(％): —
V (％):0.30
Condition of heat treatment: Annealed
Tensile strength, σb ≥/MPa: -
Yield strength, σ0.2 ≥/MPa:-
Elongation, δ ≥(％): -
Reduction of area, ф ≥(％): -
Hardness | HRS: ≤248

Condition of heat treatment: T, middle tempered
Tensile strength, σb ≥/MPa: -
Yield strength, σ0.2 ≥/MPa:-
Elongation, δ ≥(％): -
Reduction of area, ф ≥(％): -
Hardness | HRS: ≤285
Condition of heat treatment: HT 1022℃ ~ 1050℃ air or oil cooled, ≥620℃ X 2H, tempered
Tensile strength, σb ≥/MPa: 965
Yield strength, σ0.2 ≥/MPa: 760
Elongation, δ ≥(％): 13.0
Reduction of area, ф ≥(％): 30.0
Hardness | HRS: 302 ~ 352
Condition of heat treatment: H 1022℃ ~ 1050℃ air or oil cooled, ≥677℃ X 2H, tempered
Tensile strength, σb ≥/MPa: 825
Yield strength, σ0.2 ≥/MPa: 585
Elongation, δ ≥(％): 17.0
Reduction of area, ф ≥(％): 35.0
Hardness | HRS: 241 ~ 285

AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200


Applications:

AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200 is used in the aerospace industry for manufacturing of high-temperature bolting, valves, and valve trim, and also in steam turbines for buckets and blades.


AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200


FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.

AMS 5655 Turbine Blade Steel ASTM 422 Steel UNS S42200
