Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983
Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983
Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983
Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983
Specifications
Brand Name :
TOBO
Model Number :
Spring split Washers
Certification :
SGS BV ROHS etc
Place of Origin :
China
MOQ :
1Kg
Price :
1000-2200USD/ton
Payment Terms :
D/A, T/T, Western Union, MoneyGram
Supply Ability :
Max 100-150 tons/month
Delivery Time :
15-30 days
Packaging Details :
Neutral packaging or customized packaging
Product name :
standard spring washer
Standard :
GB DIN JIS ANSI
Application :
Heavy Industry, Mining, Retail Industry, General Industry, Oil & Gas,
Package :
Box Packing+carton+pallets
Material :
Brass, Stainless Steel, Steel, Alloy steel/Carbon steel/Stainless st
Size :
2#-3inch
Surface :
zinc ,black oxide ,nickel ,ruspert,HDG,Dacromet
Style :
Split, Wedge, Internal Tooth, External Tooth, countersunk, Bonde
Color :
Sliver or as your request
Description
Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983

The gasket is a thin plate (usually round) with a hole (usually in the middle) that is usually used to distribute the load thread fastener.Other uses are as spacers, springs (Belleville gaskets, wave gaskets), wear pads, pre-display devices, and locking devices.Rubber gaskets are also used in faucets (valves) to cut off the flow of liquid or gas.Rubber or silicon gaskets can also be used to reduce fan vibration.Usually the outer diameter of the gasket is about twice the inner diameter.

Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983

Products name
Ansi/Asme B 18.21.1 - 1983 Regular Helical Spring Lock Split Washers
Material
Brass, Stainless Steel, Steel, Alloy steel/Carbon steel/Stainless st
Size

2#-3inch
Surface treatment
Black/grey phosphate, zinc plated, nickel-plated, Rupert
Application
Heavy Industry, Mining, Retail Industry, General Industry, Oil & Gas,
Style
Box Packing+carton+pallets
Size ID(mm) OD(mm) Thickness(mm) Unit weight,Kg/1000pcs
min max min max min max
SAE NO.4 3.05 3.37 7.8 8.12 0.64 1.01 0.29
SAE NO.6 3.84 4.17 9.40 9.91 0.91 1.65 0.66
SAE NO.8 4.65 4.98 11.00 11.51 0.91 1.65 0.87
SAE NO.10 5.44 5.77 12.57 13.08 0.91 1.65 1.12
SAE NO.12 6.22 6.73 14.15 14.66 1.30 2.03 1.81
SAE 1/4 7.01 7.52 15.75 16.26 1.30 2.03 2.21
SAE 5/16 8.61 9.12 17.30 17.86 1.30 2.03 2.51
SAE 3/8 10.19 10.69 20.45 21.00 1.30 2.03 3.46
SAE 7/16 11.79 12.29 23.24 23.80 1.30 2.03 4.48
SAE 1/2 13.36 13.87 26.80 27.74 1.88 3.07 9.02
SAE 9/16 14.96 15.47 29.18 30.12 1.88 3.07 10.43
SAE 5/8 16.48 17.42 33.15 34.09 1.88 3.07 13.59
SAE 3/4 20.45 21.39 37.13 38.07 2.74 4.06 20.11
SAE 7/8 23.65 24.58 44.27 45.21 2.74 4.06 31.12
SAE 1 26.80 27.74 50.62 51.56 2.74 4.06 40.67
SAE 1-1/8 31.57 32.51 56.97 57.91 2.74 4.06 49.41
SAE 1-1/4 34.75 35.69 63.32 64.26 3.45 4.88 75.03
SAE 1-3/8 37.92 38.86 69.67 70.61 3.45 4.88 91.1
SAE 1-1/2 40.10 42.04 76.02 76.96 3.45 4.88 110.8
USS 3/16 NO.4 6.22 6.73 14.15 14.66 0.91 1.65 1.81
USS 1/4 7.80 8.41 18.47 19.02 1.30 2.03 3.04
USS 5/16 9.40 9.91 22.05 22.99 1.63 2.64 5.8
USS 3/8 11.00 11.51 25.22 26.16 1.63 2.64 7.42
USS 7/16 12.57 13.08 31.57 32.51 1.63 2.64 11.83
USS 1/2 14.15 14.66 34.75 35.69 2.18 3.35 18.3
USS 9/16 15.75 16.26 37.13 38.07 2.18 3.35 20.48
USS 5/8 17.30 18.24 44.37 45.21 2.74 4.00 36.57
USS 3/4 20.45 21.39 50.62 51.56 3.10 4.50 52.49
USS 7/8 23.65 24.58 56.97 57.91 3.45 4.88 71.75
USS 1 26.80 27.74 63.32 64.26 3.45 4.88 87.59
USS 1.1/8 31.57 32.51 69.67 70.61 3.45 4.88 102.44
USS 1.1/4 34.75 35.69 76.02 76.96 3.45 4.88 121.08
USS 1.3/8 37.85 39.24 82.30 83.69 3.89 5.41 159.73
USS 1.1/2 41.02 42.42 88.65 90.04 3.89 5.41 184.19
USS 1.5/8 44.20 45.59 95.00 96.39 3.89 5.41 210.36
USS 1.3/4 47.37 48.77 101.35 102.74 3.89 5.41 238.28
USS 1.7/8 50.55 51.49 107.70 109.09 3.89 5.41 267.92
USS 2 53.72 55.12 114.05 115.44 3.89 5.41 299.32
USS 2-1∕4 60.08 61.46 120.4 121.79 4.91 6.29 387.49
USS 2-1∕2 66.43 67.81 126.75 128.14 5.33 7.11 460.45
USS 2-3∕4 72.77 74.67 133.1 135 5.79 7.87 544.46
USS 3 79.12 81.02 139.45 142.35 6.32 8.3 631.12
Products Description

Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983

Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983

Package & Shipping
Alloy Steel Special Nickle Alloy 600 Regular Helical Spring Lock Split Washers Ansi/Asme B 18.21.1 - 1983
Package details:
1) Sample order, 20/25kg per carton with our logo or neutral package;
2) For Large orders, we can custom packaging;
3) Normal Packing: 1000/500/250pcs per small box. then into cartons and pallet;
4) According to customers' requirements.
FAQ
1.How do you let me trust you?

We are a Golden supplier in Alibaba who do business for more than 5 years. You can make an order by Alibaba to us directly.

2.How about your price?

High-quality products with a reasonable price suitable for your market.

3.How do you control your quality?

We request a QC inspection for each batch of goods. And we can provide you inspection report and mill certificate if you want..

4.Could you provide free samples?

For new customers, We can provide free samples for standard fasteners. But the clients will pay the express charges. For regular customers, We will send you free samples and pay express charges by ourselves.

5.How about your delivery time?

Generally speaking, All the goods have stock with little quantity, we can delivery them with one week. If the quantity is 1-2container, we can give you with 30-45days.

6.What is your packing?

Our packing is 20-25kg for one carton,36 or 48pcs cartons for one pallet. One pallet is about 900-960kg, We also can make the customer's logo on the cartons. Or we customized cartons according to customers' requirement, If you need small box packing, we can do according to your requirement.

7.What is your payment term?

We can accept T/T,LC for general order. For new customer, we request 20%-50% T/T in advance, and balance payment should against B/L copy. For regular customer, we can provide delay payment after B/L date about 30-90 days.
