Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270
Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270
Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270
Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270
Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270
Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270
Specifications
Brand Name :
CHENGYU
Model Number :
50.8*1.5
Certification :
ISO
Place of Origin :
CHINA
MOQ :
50KG
Price :
3.0-8.0USD/KG
Payment Terms :
Western Union, L/C, T/T
Delivery Time :
according to quantity
Packaging Details :
wooden case package,woven bags
Material :
304,316L,321,321H,310S,347,347H,904L
Shape :
Round
Type :
Seamless
Surface Finish :
Brush Polish,hairline,160grit,mirror ETC,bright
High Light :
sanitary stainless steel tube
Useage :
food grade stainless steel pipe
Description

Quick Details

Standard:JIS,AISI,ASTM,GB.DIN.EN.GOST

Type:Seamless Sanitary Stainless steel pipes

Grade:201/204/304L/304LN/304H/316Ti/316L/316H/321/321H/904L/310S/347 Etc

Size:OD3mm-168mm Wt 0.5mm-10mm LENGTH 50mm-12000mm

Application:Petroleum,Chemical Engineering,Fluid Machinery,Irrigation Works,Electric Power,Environmental,Etc

Surface Finish:Brush Polish,Hairline,160grit,Mirror,Bright,Etc

Technique:Cold rolling,cold drawing

Test:Hardness Test,Hydrostatic Test,Ultrasonic Test,Eddy Current Test,Dimensional Checking,Chemical Analysis Etc.

Inspection:100%

Price Term:FOB,CFR,CIF or as negotiation

Name ASTM A270 TP304L 50.8MM THK 1.5MM STAINLESS STEEL POLISHING TUBES
Items round tubes
Standard ASTM ,GB,DIN AISI
Material Grade 304: Ni 8%, Cr 18%
304L: Ni 8%, Cr 18%
316L:Ni 10%, Cr 16%
Outer Diameter Round pipe 8MM-254MM
square 12.7x12.7--200X200mm
rectangular 20X40--150X200mm
Thickness 0.8mm - 3mm
Length 5.8m,6m, or as customers' request
Tolerance a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 0.02mm
c) Length: +/- 5mm
Surface 180Grit, 320Grit, 400Grit Satin / Hairline
400Grit, 500Grit, 600Grit Mirror finish
Application food grade,exhausting,water
Test Squash test, extended test, water pressure test,heat treatment, NDT
Chemical Composition of Material Material 304L 316L 304
C ≤0.035 ≤0.035 ≤0.08
Si ≤1.00 ≤1.00 ≤1.00
Mn ≤2.00 ≤2.00 ≤2.00
P ≤0.045 ≤0.045 ≤0.045
S ≤0.03 ≤0.03 ≤0.03
Cr 18-20 16-18 18-20
NI 8-12.0 10-14.0 8-10.5
Mechanical Property Material Item 304L 316L
Tensile Strength ≥515 ≥515
Yield Strength ≥205 ≥205
Extension ≥35% ≥35%
Hardness (HV) N/M N/M

ASTM Chemical Composition (%,max)
Grade C ≤ Si ≤ Mn ≤ P ≤ S ≤ Ni ≤ Cr ≤ Mo Others
304 0.08 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00
304H 0.04-0.1 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00
304L 0.035 0.75 2 0.04 0.03 8.00-13.00 18.00-20.00
304N 0.08 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00 N:0.1-0.16
304LN 0.035 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00 N:0.1-0.16
309 0.15 0.75 2 0.04 0.03 12.00-15.00 22.00-24.00
310 0.15 0.75 2 0.04 0.03 19.00-22.00 24.00-26.00
316 0.08 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00
316H 0.04-0.1 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00
316L 0.035 0.75 2 0.04 0.03 10.00-15.00 16.00-18.00 2.00-3.00
316N 0.08 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00 N:0.1-0.16
316LN 0.035 0.75 2 0.04 0.03 10.00-15.00 16.00-18.00 2.00-3.00 N:0.1-0.16
317 0.08 0.75 2 0.04 0.03 11.00-14.00 18.00-20.00 3.00-4.00
321 0.08 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Ti:5xC%-0.70B
321H 0.04-0.1 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Ti:4xC%-0.6
347 0.08 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Nb+Ta:10xC%-1.00
347H 0.04-0.1 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Nb+Ta:8xC%-1.00
329 0.089 0.75 2 0.04 0.03 2.50-5.00 23.00-28.00 1.00-2.00
316Ti 0.08 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00 Ti:5xC%-0.75
S31803 0.03 1.00 2 0.03 0.02 4.5-6.5 21.00-23.00 2.50-3.50 N:0.08-0.3

Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270

Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270

Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270

Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270

Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270

Chemical Engineering Seamless 160 Grit Stainless Sanitary Pipe 304 ASTM A270

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)

40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)

40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)

20 feet container load 25tons pipes whose length is under 5.8m

40 feet container load 28tons pipes whose length is under 11.8m

Q1: Wonder if you accept small orders?

A1: Do not worry. Feel free to contact us. In order to get more orders and give our clients more convener ,we accept small order.

Q2: Can you send products to my country?

A2: Sure, we can. If you do not have your own ship forwarder, we can help you.

Q3: Can you do OEM for me?

A3: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.

Q4: What's your payment terms ?

A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.

Q5: How long is your production lead time?

A5:It depends on product and order qty. Normally, it takes us 15 days for an order with MOQ qty.

Q6: When can I get the quotation ?

A6: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
