1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L
1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L
1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L
1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L
Specifications
Brand Name :
CHENGYU
Model Number :
168.3*7.11
Certification :
ISO
Place of Origin :
CHINA
MOQ :
50KG
Price :
2.0-3.0USD/KG
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000TONS PER YEAR
Delivery Time :
5-15DAYS
Packaging Details :
Plastic Bag,Plywooden case,Iron Steel Case
Steel grade :
300 Series,400 Series,200 Series,Duplex Stainless steel,600 Series
Type :
Welded
Welding line type :
ERW,EFW
Standard :
EN,ASTM,AISI,DIN,JIS
Application :
Decoration,Industry,Railing & baluster constrcution Decoration
Shape :
Round.square.Rectangle,Round.square.Rectangle .Flat.Oval. Solid
Surface :
Annealed/Pickling/Polished/Brushed/Sand-blasted finished
Product name :
ss AISI 201 304 310 316 409 430 Welded Stainless Steel Pipe
Price term :
CIF,etc.,FOB,CFR,EX-WORK
Description
Overview

Quick Details

Standard:JIS,AISI,ASTM,GB,DIN,EN,GOST

Type:Welded

Grade:201/304/304L/304LN/304H/316Ti/316L/316H/321/321H/904L/310S/347 etc

Size:OD6mm-1024mm WT0.5mm-68mm LENGTH 50mm-12000mm

Application:Pipe and Tubes for petrochemical industry,Pharmaceutical industry,Food industry,Aviation and aerospace industry,Architectural decoration industryEtc

Surface Finish:Brush polish,Hairline,160grit,Mirror,Bright,Etc

Test:Hardness Test,Hydrostatic Test,Ultrasonic Test,Eddy Current Test,Dimensional Checking,Chemical Analysis Etc

Inspection:100%

Price Term:FOB,CFR,CIF or as negotiation

Such below defects not allowed:

1. Internal surface defects

Features: Straight or spiral or semi-helical serrated defects appear on the inner surface of the steel pipe.

Causes:

1) Tube billet: loose center and segregation;Serious residual shrinkage cavity;Non-metallic inclusions exceed standard.

2) Uneven heating, too high or too low temperature and too long heating time of tube billet.

3) Perforation area: severe wear on the top;Punching machine parameters are not adjusted properly;Perforated roll aging, etc.Inspection: the inner surface of the steel pipe is not allowed to have an inner fold. The inner fold of the pipe end should be polished or re-cut. The actual wall thickness of the polished place should not be less than the minimum value required by the standard.Through the length of the internal fold to reject.

2. Internal scarringCharacteristics: the inner surface of the steel tube shows spots and scars, generally not rooting easy to peel off.

Name 304 316 316L welded large diameter stainless steel pipe for industry
Items Round tubes ,welded
Standard ASTM ,GB,DIN AISI
Material Grade 316L:Ni 10%, Cr 16%
304L: Ni 8%, Cr 18%
304: Ni 8%, Cr 18%
Outer Diameter Round pipe9.5mm--813mm
square 12.7x12.7--200X200mm
rectangular 20X40--150X200mm
Thickness 0.8mm - 34mm
Length 5.8m,6m, or as customers' request
Tolerance a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 0.02mm
c) Length: +/- 5mm
Surface annealing,pickling
sandblasting
Application industry,exhausting,water
Test Squash test, extended test, water pressure test,heat treatment, NDT
Chemical Composition of Material Material 304L 316L 304
C ≤0.035 ≤0.035 ≤0.08
Si ≤1.00 ≤1.00 ≤1.00
Mn ≤2.00 ≤2.00 ≤2.00
P ≤0.045 ≤0.045 ≤0.045
S ≤0.03 ≤0.03 ≤0.03
Cr 18-20 16-18 18-20
N 8-12.0 10-14 8-10.5
Mechanical Property Material Item 304L 316L 304
Tensile Strength ≥515 ≥515 ≥515
Yield Strength ≥205 ≥205 ≥205
Extension ≥35% ≥35% ≥35%
Hardness (HV) N/M N/M

N/M

ASTM Chemical Composition (%,max)
Grade C ≤ Si ≤ Mn ≤ P ≤ S ≤ Ni ≤ Cr ≤ Mo Others
304 0.08 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00
304H 0.04-0.1 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00
304L 0.035 0.75 2 0.04 0.03 8.00-13.00 18.00-20.00
304N 0.08 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00 N:0.1-0.16
304LN 0.035 0.75 2 0.04 0.03 8.00-11.00 18.00-20.00 N:0.1-0.16
309 0.15 0.75 2 0.04 0.03 12.00-15.00 22.00-24.00
310 0.15 0.75 2 0.04 0.03 19.00-22.00 24.00-26.00
316 0.08 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00
316H 0.04-0.1 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00
316L 0.035 0.75 2 0.04 0.03 10.00-15.00 16.00-18.00 2.00-3.00
316N 0.08 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00 N:0.1-0.16
316LN 0.035 0.75 2 0.04 0.03 10.00-15.00 16.00-18.00 2.00-3.00 N:0.1-0.16
317 0.08 0.75 2 0.04 0.03 11.00-14.00 18.00-20.00 3.00-4.00
321 0.08 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Ti:5xC%-0.70B
321H 0.04-0.1 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Ti:4xC%-0.6
347 0.08 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Nb+Ta:10xC%-1.00
347H 0.04-0.1 0.75 2 0.04 0.03 9.00-13.00 17.00-20.00 Nb+Ta:8xC%-1.00
329 0.089 0.75 2 0.04 0.03 2.50-5.00 23.00-28.00 1.00-2.00
316Ti 0.08 0.75 2 0.04 0.03 11.00-14.00 16.00-18.00 2.00-3.00 Ti:5xC%-0.75
S31803 0.03 1.00 2 0.02 0.02 4.5-6.5 21.00-23.00 2.50-3.50 N:0.08-0.2
S32750 0.03 0.80 1.2 0.03 0.015 6.0-8.0 24.00-26.00 3.00-5.00 N:0.24-0.32

1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L

1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L

1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L

1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L

1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L

1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L

1.4404 Stainless Steel Welded Pipe 6 Inch Stainless Steel Tubing 316L

Q1: How do u guarantee the pipes quality?

A1:Test all the incoming raw material,and full monitoring of production,When pipes finished ,inspect all the pipes if quality good then ship out.

Q2: Can you send products to my country?

A2: Sure, we can. If you do not have your own ship forwarder, we can help you.

Q3: Can you do OEM for me?

A3: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.

Q4: What's your payment terms ?

A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.

Q5: How long is your production lead time?

A5:It depends on product and order qty. Normally, it takes us 15 days for an order with MOQ qty.

Q6: When can I get the quotation ?

A6: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
