Specifications
Brand Name :
SINOY
Model Number :
304
Certification :
ISO, SGS , TUV
Place of Origin :
CHINA
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
2000 Tons
Delivery Time :
5-7 days
Packaging Details :
waterproof paper and steel strip reinforcement steel strip reinforcement,one package about 2.5 tons, 20' / 40'
Material /Grade :
201 202 304 304L 316L 321 310S 430
Standard :
ASTM A554 A312, JIS G3446, CNS5802
Size :
6-630 mm
Thickness :
0.1-50 mm
Length :
6 m
Tolerance :
OD +- 0.2 mm ; Thk +-0.02 mm
Technique :
Welded / ERW
Surface Finish :
240G, 320G, 400G, 600G, 800G, BA,Mill Finish , Matte finish , Stain finish , Brush，
End Treatment :
Threaded, Beveled, Plain, Screwed, Etc.
End Protector :
Plastic Cap, Coupling, Nipple, Elbow, Tee, Flange And Some Other Pipe Fittings
Trade Term :
Ex-Work, FOB, CNF, CFR, CIF, Etc
FOB Port :
Shanghai Or As Required
Name :
201 304 Decorative Steel Pipe 25.4 x 1.5 mm , stainless steel welded tube
Description

Ss TP304 TP316L Pipe Stainless Steel Welded Tube Pipe Stock Round Tube

Stainless steel tube are also called stainless steel welded pipes for short. Commonly used steel or steel strips are welded into steel pipes after being curled and formed by the machine and the die. Welded steel tube has the advantages of simple production process, high production efficiency, many varieties and specifications, and less equipment, but its general strength is lower than that of seamless steel pipe.

Stainless Steel Welded Tube
(304 304L 316L 321 310S 309S 430 2205 904L)
630*8 159*6 108*3 60*3.5 45*6 32*5 18*3
530*8 159*5 102*6 60*3 45*5 32*4 18*2.5
480*8 159*4 102*5 57*13 45*4 32*3.5 18*2
426*10 159*3 102*4 57*12 45*3.5 32*3 16*3
426*7/8 140*4.5 89*10 57*10 45*3 32*2.5 16*2.5
426*6 140*4 89*8 57*8 45*2.5 32*2 16*2
377*10 133*12 89*6 57*6 45*2 30*3 14*3
377*7 133*8 89*5 57*5 42*10 28*3 14*2
377*8 133*6 89*4.5 57*4.5 42*7/8 27*5 12*2
377*6 133*5 89*4 57*4 42*6 27*4 12*1
325*8 133*4.5 89*3.5 57*3.5 42*5 27*3 10*2
325*6 133*4 89*3 57*3 42*4 27*2 10*1
273*8 133*3 89*2.5 57*2.5 42*3.5 25*4 8*1
273*6 120*8 89*2 57*2 42*3 25*3 6*1
273*5 120*6 76*8 51*10 38*6 25*2.5*6
219*8 120*5 76*6 51*8 38*5 25*2.5
219*6 120*4.5 76*5 51*6 38*4 25*2*6
219*5 120*4 76*4 51*5 38*3 25*2
219*4.5 120*3.5 76*3.5 51*4 38*2.5 22*6
219*4 114*8 76*3 51*3.5 38*2 22*5
194*4.5 114*6 76*2.5 51*3 34*7 22*4
180*5 114*5 76*2 48*10 34*6 22*3
168*8 114*4 60*12 48*8 34*5 22*2
168*6 114*3 60*10 48*6 34*4 21*3
168*5 108*8 60*8 48*5 34*3.5 20*3
168*4 108*6 60*6 48*4 34*3 20*2
166*4.5 108*5 60*5 48*3.5 34*2.5 19*3
162*5 108*4.5 60*4.5 48*3 32*8 19*2.5
159*8 108*4 60*4 45*8 32*6 19*2

Editing of Decorative Steel Pipe Technology
A board, belt preparation
B split
C molding
D welding
E cutting
F grinding
G polishing

Data Compare with stainless steel pipe grades:

C Si Mn P S Ni Cr Mo
201 ≤0.15 ≤1.00 ≤5.5-7.0 ≤0.060 ≤0.030 3.50-5.50 16.00-18.00
202 ≤0.15 ≤1.00 ≤7.50-10.00 ≤0.060 ≤0.030 4.0-6.0 17.0-19.0 ---
304 ≤0.07 ≤1.00 ≤2.00 ≤0.035 ≤0.030 8.00-11.00 17.00-19.00 ---
304L ≤0.03 ≤1.00 ≤2.00 ≤0.035 ≤0.030 8.00-12.00 18.00-20.00 ---
316 ≤0.08 ≤1.00 ≤2.00 ≤0.035 ≤0.030 10.00-14.00 16.00-18.50 2
316L ≤0.03 ≤1.00 ≤2.00 ≤0.035 ≤0.030 12.00-15.00 16.00-18.00 2
430 ≤0.12 ≤0.75 ≤1.00 ≤0.04 ≤0.030 ≤0.60 16.00-18.00 ---

How Can You Ship Goods Stainless Steel pipe?

  • Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
  • We pack our goods in numerous ways based on the products. We pack stainless steel welded tube in multiple ways, such as,
    • Waterproof paper reinforcement of steel strip
    • Kraft paper
    • Carton boxes
    • Wooden pallets
    • Wooden boxes
    • Wooden crates

Ss TP304 TP316L Pipe Stainless Steel Welded Tube pipe Stock round tube

Marking service

  • We mark all our products with entire details which are connected to the test certificates we provide.
  • Surface is sprayed with code.

  • We have our own machines to help our partner. Can spray grade, size, and standard.

    . Drop on demand

    . Continue ink jet printer

    . Laser printer

Factory of Decorative Steel Pipe
