600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
Specifications
Brand Name :
JISCO, LISCO, TISCO ,BAO STEEL POSCO/ ZPSS ,SINOY
Model Number :
316 / 316L / 316Ti
Certification :
ISO, SGS, TUV, ISO
Place of Origin :
CHINA
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
2000 Tons
Delivery Time :
5-7 days
Packaging Details :
waterproof paper and steel strip reinforcement steel strip reinforcement,one package about 2.5 tons, 20' / 40'
Other Material :
201 304 304L 2205 Duplex
Product :
Stainless Steel Welded Round Tube / Pipe
Surface :
Mirror , 400 grit & Mill finish, polish, 600G, 800G
Wall Thickness :
0.3-50 mm
Length :
6000 mm
OD :
6-720 mm
Technique :
Welded ,ERW
Tolerance :
Thickness: +/- 0.02mm Length: +/- 5mm
Trade Term :
Ex-Work, FOB, CNF, CFR, CIF, Etc
FOB Port :
Shanghai Or As Required
Description
600G 800G Mirror 316 / 316L / 316Ti Stainless Steel Welded Round Tube / Pipe
Sino Stainless Steel

Sino Yuan is one of most prominent Stainless Steel Stockholder and Service Center providing Stainless Steel

to various industries in the region. Sino Yuan's stock holds the entire range of stainless steel like sheets, coils,

pipes for decoration and industry,round bars in different grades ( 304 304L 316 316L 321 310S 309S 310S

2205 904L)and sizes specially stocked to meet the local industrial demands as well as the International Mraket.

012 cr17ni12mo2 (old version 0 cr17ni12mo2)

TP316L Stainless Steel pipe Chemical composition:
C Si Mn Cr Ni S P
0.03 ≤1.0 ≤2.0 16.0~18.0 10.0~14.0 ≤0.03 ≤0.045
TP316L Stainless Steel pipe mechanical properties:
Tensile strength σb (MPa) Conditions yield strength 0.2 sigma (MPa) Elongation % (min) Hardness
520 205 40 ≤187HB ≤90HRB ≤200HV

Is there any guarantee of SINO Stainless Steel Pipe ?

Factory supply inspection before shipment,sampling test( cut one piece for you to test in our lab or some other lab like SGS which you trust so much) ,

you also could inspection of loading on the forwarder warehouse or our Mill.

Editing of Stainless Steel Welded Round TubeTechnology
A board, belt preparation
B split
C molding
D welding
E cutting
F grinding
G polishing

Specifications data of stainless Steel Welded Tube:

Size (mm) Quantity Size (mm) Quantity Size (mm) Quantity
6-12×1.5-2.5 18

73×4-4.5-5-6-7-8-9-10-12-15

 50 219×30-40 65
14×1.5-2.5-3 20

76×4-4.5-5-6-7-8-9-10-12-14

 60 245×8-10-14-17-20-22 105
16×1.5-2.5-4 30 83×4.5-5-10 30

245×25-28-30-34-40

 84
18×2.3-4-5 20 89×4.5-8-10 40

273×7-9-12-15-18-20-25

 100
20×2.5-3-5 17

95×4.5-6-8

 50 273×30-35-38-40 50
24×2.5-3-4-5-6 25 102×4.5-5-6-10-12-14-16-20 80

299×8-12-16-20-24-28

 60
25×2.5-3-4-5-6 28 108×4.5-5-14-18-20-22 75

299×30-32-36-38-40

 70
28×3-3.5-4-5-6 30

114×4.5-5-6-7-8-10-12-14-18-20

 100 325×8-12-14-18-38 120
32×3.5-4-5-6-8 40

121×4.5-5-6-7-8-10-12-14-16-20

 102 325×28-32-34-38 75
34×4-5-6-8 35

127×4.5-5-6-7-8-10-12-14-16-20

 95 351×10-16-20-25-40 120
36×3.5-5-6-8 30

133×4.5-6-8-12-14-16-18-20-25-30

 120 355×6-18-20-25-30-40 45
38×4-5-6-7-8-9-10 33 140×5-6-7-8-9 50

377×8-12-15-20-24-28

 128
39×3.5-5-8-10 30

146×4.5-6-8

 60 377×30-37-40 60
42×3.5-4-5-6-7-8-9-10 35

152×4.5-6-8

 60 402×10-20-25-30-35 70
45×3.5-4-5-6-7-8-9 40 159×4.5-6-10-12-14 80 406×10 110
48×3.5-4-5-6-7-8-9-10 24 159×16-18 30 426×10 97
51×3.5-4-5-6-7-8-9-10 60 168×8-25-30-35 130 450×10-20-25-34-40 108
56×3.5-4-5-6-7-8-9-10 58 180×8-12-16-25-30 105 480×25-30-40 95
57×3.5-5-6-7-8-9-10-12 50 180×32-34-38-40 102 500×10-34-40-45 100
60×3.5-4.5-5-6-7-8-9-12-14 60 194×6-8-25-30-40 140 510×10-25-34-40-45 110
63×3.5-4.5-5-6-7-8-9-10-12-14 40

203×6-7-10-15-20-25-30

 90 530×20-30-40 140
68×4-4.5-5-6-7-8-9-10-12-14-16 35 203×32-36-40 70 560-720*6-10-24-45
70×4-4.5-5-6-7-8-9-10-12-15-16 40

219×6-8-12-16-18-20-25

 110

What Is Best Pacakge of 316 / 316L / 316Ti Stainless Steel Welded Round Tube / Pipe ?

  • We pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,
    • Waterproof paper reinforcement of steel strip
    • Kraft paper
    • Carton boxes
    • Wooden pallets
    • Wooden boxes
    • Wooden crates

  • Marking service is available to you.

    Surface is sprayed with code.

    We have our own machines to help our partner. Can spray grade, size, and standard.

    1. Drop on demand

    2. Continue ink jet printer

    3. Laser printer

600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface600G 800G Stainless Steel Welded Tube CNS5802 Mirror Finish Surface
