Specifications
Brand Name :
SINOY
Model Number :
2205
Certification :
SGS,TUV , ISO
Place of Origin :
CHINA
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
800 Tons per month
Delivery Time :
5-7 days
Packaging Details :
hot rolled waterproof paper and steel strip reinforcement,one package about 2 tons,Load in 20GP /40GP
Name :
ASTM A240 Duplex 2205 Stainless Steel plate hot rolled steel sheet No.1 finish
Grade :
2205
Thickness :
3-6mm , 8mm , 10mm , >=12mm
Width :
1240mm , 1500mm , 2000mm
Finish :
NO.1
Length :
1000-6000mm As Your Request
Shape :
sheet /plate/ coil
Mill :
TISCO SINOY
Edge :
Still , Mill
Technique :
Hot rolled
Other material :
201 202 304 304L 430 321 309s 310s 904L Ect
Description

ASTM A240 Duplex 2205 Stainless Steel plate hot rolled steel sheet No.1 finish

Wuxi Sino Yuan Science and Technology Co.,Ltd is one of the toppest 2205,2205 stainless steel plate,China steel supplier in China.During these years of exporting , Wuxi Sino Yuan Science and Technology Co.,Ltd now has rich .

specification Thickness:3-6.0mm 8mm , 10mm , >=12mm
Width:500-2000mm normal size1000 1219 1220 1240 1250 1500 2000mm Length:1000-6000mm normal size 2438 2440 3000 6000mm
Mill TISCO BAOSTEEL LISCO BAOXIN ZPSS JISCO
Finish No.1
Edge Mill /raw , slit edge
Weight ThicknessXWidthXLengthX8.0 (2205 per sheet
Technique hot rolled
Payment term 30% T/T in advance,the balance before shipment 30% T/T in advance,the balance L/C at sight 100% L/C at sight
Packing 1.Export sea worthy package + water proof paper + wooden pallet 2.Max Loading 25mt for each 20GP container 3.Safe loading and fixing Professional Teams
Delivery time Within 5-7 days after received 30%T/T of deposit
Trade terms FOB Shanghai CNF , CFR&CIF your port
Quality control Mill Test Certificate is supplied with shipment
Application 1.Construction field, shipping building industry
2. Petroleum and Chemical Industries 3.Food and Mechanical Industries

Duplex 2205 Stainless Steel

The main alloying elements of duplex steel are Cr, Ni, Mo and N. Among them, Cr and Mo increase ferrite content, while Ni and N are austenite stable elements. Some steels also contain elements such as Mn, Cu and W. Cr, Ni and Mo can improve the corrosion resistance. In the chloride-containing environment, its pitting and crack corrosion resistance is particularly good.

CHEMICAL COMPOSITION

2205 C Si Mn P S Ni Cr Mo N
≤0.03 ≤1.00 ≤2.00 ≤0.030 ≤0.015 4.50~6.50 21.00~23.00 2.90~3.50 0.14~0.20

MECHANICAL PROPERTY Duplex 2205 Stainless Steel plate

2205 σb (MPa)≥620
σ.2 (MPa)≥450
δ5 (%)≥18
≤320HV
8.0 g/cm3
2205 σb (MPa)≥620
σ0.2 (MPa)≥450
δ5 (%)≥18
≤320HV

Duplex 2205 Stainless Steel plate

Standard: ASTM A240/A240M--01 chromium 2205 duplex stainless steel alloy is a 22%, 2.5% 4.5%-NI-n alloy composition Mo and duplex stainless steels. It has high strength, good toughness and good global and local resistance to stress corrosion.

Heat treatment performance:

2205 alloy should be annealed at the lowest temperature of 1900º F, then cooled rapidly and quenched by water. This treatment is applied to solid melting annealing and stress relief. Stress relief treatment, if carried out at temperatures below 1900º F, can easily lead to the precipitation of harmful metal or non-metal phases.

Duplex2205 stainles steel Product Introduction :

At present, 2205 stainless steel products in China include

2205 stainless steel tubes,

2205 duplex stainless steel seamless tubes,

2205 duplex stainless steel plates,

2205 stainless steel bars,

forgings, fittings, strips, etc.

Packing & Factory

2205 Duplex Stainless Steel Pipe Machining , Duplex 2205 Plate ASTM A240 Customized2205 Duplex Stainless Steel Pipe Machining , Duplex 2205 Plate ASTM A240 Customized

If anything is interested, please freely contact me, looking forward to your inquiry
