2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B
Specifications
Brand Name :
SINOY
Model Number :
410S
Certification :
SGS, TUV, ISO
Place of Origin :
CHINA
MOQ :
1 Tons
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
800 Tons per month
Delivery Time :
3-5 working days for regular size,
Packaging Details :
cold rolled waterproof paper and steel strip reinforcement,one package about 2 tons,Load in 20GP
Name :
410 / 410S 2B Stainless Steel Plate BAOSTEEL
Other grade :
201 202 304 304L 316L 321 310S 430 2205 904L Duplex
Finish :
BA, 2B , HL , Mirror , polish , brush , PVC
Standard :
JIS, AISI, ASTM, GB, DIN, EN ,etc
Thickness :
0.3-6 mm
Width :
1000mm, 1219mm, 1500mm or as customized
Length :
2400 2440 2000 3000mm or as customized
Tolerance :
Thk +/- 0.02 mm
Edge :
Slit,Mill
Quality control :
Mill Test Certificate is supplied with shipment
Description

410 / 410S 2B Stainless Steel Plate BAOSTEEL , Cold Rolled Steel Sheet

Description:

Grade : 410S / 410

Thickness : 0.3-3mm
Tolerance : +/- 0.02mm
Width: 1000mm 1219mm 1220mm 1240mm 1500mm or as customized
Length : 2000mm 2400mm 2440mm 3000mm 2500mm or as customized
Mill : BAOSTEEL

Trade term :FOB, CFR, CIF, CNF , EXW

Cold Rolled :
Cold rolled: Hot rolled coil is used as raw material, and the oxide skin is removed by pickling. The product is rolled coil. The cold work hardening caused by continuous cold deformation makes the strength, hardness and toughness and plasticity of rolled coil increase, so the stamping performance will deteriorate and can only be used for parts with simple deformation. Rolled coil can be used as raw material for hot galvanizing plant because annealing lines are set up in hot galvanizing units. The weight of rolled coil is generally 6-13.5 tons. The hot rolled pickling coil is rolled continuously at room temperature. The inner diameter is 610 mm.
Product characteristics:
Because it has not been annealed, its hardness is very high (HRB is greater than 90), and its machinability is very poor. It can only perform simple bending with direction less than 90 degrees (perpendicular to coiling direction).
Simply speaking, cold rolling is processed and rolled on the basis of hot rolled coils. Generally speaking, it is a hot rolling - Pickling - cold rolling process.
410 Chemical composition:
C Si Mn Cr Ni S P
0.15 ≤1.0 ≤1.0 11.5~13.5 ≤0.03 ≤0.04
mechanical properties:
Tensile strength σb (MPa) Conditions yield strength 0.2 sigma (MPa) Elongation % (min) Hardness
260 470 30 ≤210HV

Data of Other Grades Chemical Composition :

Typical chemical composition
% 304 304L 310S 316L
C 0-0.07 0-0.03 0.25 0.03
Mn 0-2.0 0-2.0 2.00 2
Si 0-1 0-1 1.50 0.75
P 0-0.05 0-0.05 0.045 0.045
S 0-0.02 0-0.02 0.03 0.03
Cr 17.5-19.5 17.5-19.5 24.0-26.0 16.0-18.0
Ni 8-10.5 8-10.5 19.2-22.0 10.0-14.0
Mo 0.75 2.00-3.00
N 0.1
Cu 0.50
Fe Balance Balance Balance


410 / 410S stainless steel plate surface appearance and the possibility of diversification:

  • Good corrosion resistance, longer durability than ordinary steel

  • High strength, so the possibility of using the thin plate is big

  • High temperature oxidation and strength, so it can resist fire

  • Normal temperature processing, that is, easy to plastic processing

  • Because it is not necessary to surface treatment, so simple, easy to maintain, clean, high finish, good welding performance

Inspection :

Factory supply inspection before shipment,sampling test( cut one piece for you to test in our lab or some other lab like SGS TUV which you trust )

you also could inspection of loading on the forwarder warehouse or our Mill.

2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B

Factory and Machinery Equipment :

We had our own factory to do slitting re-rolling and finish treatment machine,PVC and interleaving paper we will using with our machine for you,could protect stainless steel surface from damage or any scratches,

1. CNC Flame Cutting Machine

2. CNC Plasma Cutting Machine

3. CNC Laser Cutting Machine

4. Bending Machine

5. Shearing Machine

6. Punch Machine

7. Driving Machine

2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B

Packing

cold rolled waterproof paper and steel strip reinforcement,one package about 2 tons,Load in 20GP / 40GP

2000mm 2400mm 2440mm Solid Stainless Steel Diamond Plate 1mm 410 / 410S 2B


If anything is interested, please freely contact us, looking forward to your inquiry
