0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service
Specifications
Brand Name :
TISCO BAOSTEEL
Model Number :
Carbon Steel Sheet
Certification :
SGS BV
Place of Origin :
China
MOQ :
1 ton
Price :
To be negotiated
Payment Terms :
L/C, T/T
Supply Ability :
8,000 ton per month
Delivery Time :
10-15 days after advance payment
Packaging Details :
Kraft paper, wooden case, packaging according to customer requirements
Name :
ASME SA106 Grade B seamless carbon steel pipe for high-temperature service
Material :
a36 A283 A387 1008 4320 SS400 S235jr
Surface :
Galvanized Coated,Black Painted,PE coated,Black Painting or Galvanized,etc.
Length :
1000-12000mm,As Customers' Requirement
Thickness :
0.5-100mm,6-400mm,1mm-120mm,0.15mm-300mm
Width :
600-2500mm,600mm-1250mm,1.8m,305mm/355mm/455mm/510mm
Description

ASME SA106 Grade B seamless carbon steel pipe for high-temperature service


A106 Pipe.

ASTM A106 pipe (also covered in ASME specifications as S/A 106) is the standard specification for seamless carbon steel pipe for high-temperature service. Most common uses are in refineries and plants when gasses or fluids are transported at high temperatures and pressures. Federal Steel Supply is a world leader in the supply of A106 / SA 106 pipe and stocks a full range of grades B/C in a size rage of NPS 1/8″ to NPS 48″, with nominal (average) wall thickness as given in ANSI B36.10. Pipe having other dimensions may be furnished provided such pipe complies with all other requirements of this specification*. Pipe ordered under this specification shall be suitable for bending, for flanging, for welding, and for similar forming operations. A full range of A106 stock is available in Schedules 10 through 160, STD, XS, XXS. Unscheduled wall thicknesses available up to 4 inches.
Federal Steel Supply stocks a full range of A106 seamless carbon steel pipe.
Grades B/C


Sizes


NPS 1/8″ to NPS 48”
Wall thickness: Schedules 10 through 160, STD, XS, XXS.

Product Description:


Chemical Properties %
Grade A
C
Mn
P
S
Si
Cr
Cu
Mo
Ni
V
0.25
0.27-0.93
0.035
0.035
0.1
0.4
0.4
0.15
0.4
0.08
Grade B
C
Mn
P
S
Si
Cr
Cu
Mo
Ni
V
0.3
0.29-1.06
0.035
0.035
0.1
0.4
0.4
0.15
0.4
0.08
Grade C
C
Mn
P
S
Si
Cr
Cu
Mo
Ni
V
0.35
0.29-1.06
0.035
0.035
0.1
0.4
0.4
0.15
0.4
0.08

Mechanical Properties
Grade A
Grade B
Grade C
Tensile strength
330
415
485
Yield strength
205
240
275



0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service

0.5mm Asme Sa106 Grade B Seamless Carbon Steel Pipes For High Temperature Service

Shipping

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;

2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

3. Customers specifying freight forwarders or negotiable shipping methods!

Delivery Time: 3-7 days for samples; 5-25 days for batch goods.

Payment Terms

1.Payment: T/T, L/C, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.

2.MOQ: 1pcs

3.Warranty : 3 years

4.Package Informations: 1) EXPORT, In 20 feet (GW 25 ton) or 40 feet Container (GW 25 ton)

2)as customer's requirement

Why choose us?

(1) The leading exporter in China special steel industry.

(2) Large stocks for various sizes, fast delivery date.

(3) Good business relationship with China famous factories.

(4) More than 7 years steel exporting experience.

(5) Good after-sales service guarantee.
