Specifications
Brand Name :
BAOWANG
Model Number :
201,304,316L,430,etc
Certification :
ISO,SGS, CE, RoSH
Place of Origin :
CHINA
MOQ :
1 ton
Price :
USD 800-3500 USD/TON
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100 TONS PER WEEK
Delivery Time :
5-15 DAYS
Packaging Details :
STAINLESS STEEL SHEET ON PROCESSED WOODEN PALLET
Place of origin :
China
Brand name :
Baowang
Width :
1000/1219/1250/1500/1800mm or as required
Length :
1000/1500/2000/2438/2500,or as required
Surface :
BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
Finish :
Polished,Mirror,Bright,Hairline,Satin,Brushed ect.
Payment :
30%TT+70%TT / LC
Edge :
Slit Edge,Mill Edge
Technique :
Cold Rolled, Hot Rolled
Price term :
FOB,CIF,CFR,EX-WORK,FCA,etc
Delivery time :
7-15 days, depending on quantity
MOQ :
1 ton/1000 Kgs
Thickness :
0.3-300mm
Description
201 304 316 321 410 430 Stainless Steel Sheet Planchas De Acero Inoxidable Inox
Products Description

321 304 304l 316 316l stainless steel sheet

ITEM Stainless Steel Sheet/Plates
Brand TISCO, BAOSTEEL, JISCO, HONGWANG, etc.
Size Thickness 0.01mm-3.0mm or customized;Width:500-2500mm or customize
Material

201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430

.410.440.904Lect. Or Customized
Standard GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Surface 2B.NO.1.,NO.4,HL,BA,BK Or customized;
Application

Foodstuff, Gas, metallurgy, biology, electron, chemical, petroleum,

boiler, nuclear energy, Medical equipment, fertilizer etc
Package Standard export sea-worthy packing or customized
Lead Time 7-15 days after deposit
Payment TT/LC
Sample we could offer the sample for free charge but do not pay the cost of freight.
410 Stainless Steel Sheet For Commercial Kitchen Wall Acero Inoxidable SGS
2B Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface.BA surface finished is Bright heat treatment after cold rolling.No.4, also called #4, satin or directional finish, is an unidirectional finish obtained with a 100-400 grit abrasive depending on requirements. High grit numbers create finer polishing lines and more reflective finishes.Hairline referred to as "the HL",it’s grain as fine as hair, straight and continuous, delicate with oil paints on the surface. It has slightly lower reflective rate than satin stainless steel.Mirror finish is produced by progressively using finer abrasives and finishing with extremely fine buffing compounds. Mirror finish is also called 8K, No.8 and polish finish, which is the most reflective mirror finish with high quality to similar as glass mirror. The final surface is blemish free with a high degree of image clarity and is the true mirror finish.
410 Stainless Steel Sheet For Commercial Kitchen Wall Acero Inoxidable SGS
Surface Finish Definition Application
2B Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface. With bright and smooth surface ,easy for further grinding to obtain brighter surface ,suitable for medical instruments ,milk containers ,tableware and so on.
BA Bright heat treatment after cold rolling. Structual members .etc.kitchen utensil ,cutlery ,eleltric applicances ,medical instruments ,building decorations ,etc.
NO.3/NO.4 Polished with No.150-240 abrasives. Milky food processing equipment , medicalinstruments ,building decorations.
HL Finshed by polishing with abrasives of suitable grain size to obtain continuous streaks. Building decorations ,such as elevators ,escalators ,door etc.
6K/8K A mirror-like reflective surface ,which is obtained by polishing with successively finer abrasives and buffing extensively with all gritlines are removed. Buliding entrances,bulkding column casting ,elevator's wall doors ,counters,sculptures etc.

Stainless Steel Coil/Sheet/Plate Information
Technique Surface Finish Grade Series Thickness(mm) Width(mm) Application
Main Dimension
20-850 1000 1219 1240 1250 1500 Petro-chemical industry,Tanks
Construction material
Hot Rolled No.1 / 2E 201/202/
304		 2.2-12.0 √ √ √ √ √
Cold Rolled 2B 201/304 0.25-3.0 √ √ √ √ √ √
410S/430 0.25-2.0 √ √ √ √
No.4 / Hairline
Mirror / Linen
SB		 201/304 0.22-3.0 √ √ √ √ √
410S/430 0.25-2.0 √ √ √ √ √
BA 201/304 0.2--1.8 √ √ √ √
410S/430 0.25-2.0 √ √ √ √
2BA √ √ √ √

Chemical composition and mechanical properties of stainless steel coils
Grade Chemical Composition (%) Mechanieal Performece
C Si Mn P S Ni Cr Mo Hardness
201 ≤0.15 ≤1.00 5.5/7.5 ≤0.060 ≤0.030 3.5/5.5 16.0/18.0 - HB≤241,HRB≤100, HV≤240
304 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 8.0/11.0 18.00/20.00 - HB≤187,HRB≤90,HV≤200
316 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.00/14.00 16.0/18.0 2.00/3.00 HB≤187, HRB≤90 HV≤200
316L ≤0.03 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.00/14.00 16.0/18.0 2.00/3.00 HB≤187, HRB≤90 HV≤200
410 ≤0.15 ≤1.00 ≤1.25 ≤0.060 ≤0.030 ≤0.060 11.5/13.5 - HB≤183, HRB≤88 HV≤200
430 ≤0.12 ≤1.00 ≤1.25 ≤0.040 ≤0.03 - 16.00/18.00 - HB≤183, HRB≤88 HV≤200
