50mm Industrial Liquid Filled Oil Pressure Gauge Dual Scale 0 - 70 Psi
50mm Industrial Liquid Filled Oil Pressure Gauge Dual Scale 0 - 70 Psi
Specifications
Brand Name :
WESEN or Customized
Model Number :
M03.01.060.N
Certification :
CE, ISO
Place of Origin :
China
MOQ :
100 Pieces
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20000 Pieces per Month
Delivery Time :
3~4 Weeks
Packaging Details :
Carton
Size :
60mm
Mount :
Back mounting
Pressure Range :
400 bar or Customized
Case Material :
Stainless Steel 304
Lens Material :
Instrument glass
Bourton Tube :
Phosphor bronze
Movement :
Brass
Dial :
Aluminum, dual scale
Accuracy :
1.5
Liquid :
Silicone oil, glycerin
Description

60mm 400 bar Silicone Oil Filled Manometer Brass Connection Liquid-filled Pressure Gauge

Description
Liquid filled pressure gauges are designed to function in adverse conditions where pulsating pressure or vibration exists. A shock resistant Stainless Steel case protect the gauges which features phosphor bronze bourdon tube movement and a white aluminum dial with large numbers for easy reading. Range 0-300 psi. Glycerin filled.

Applications
For measuring locations with high dynamic pressure loads and vibrations
For gaseous and liquid media that are not highly viscous or crystallising and will not attack brass parts
Hydraulics
Compressors, shipbuilding
​​
Special features
Vibration and shock-resistant
Especially robust design
Completely from stainless steel
Scale ranges up to 0 ... 1000 bar

Specifications

Design

EN 837-1

Nominal size

 60mm

Accuracy

 1.6, 1.0
Pressure range 1.6MPa (customized)

Pressure limitation

40mm, 50mm, 63mm:
Steady: 3/4 x full scale value Fluctuating: 2/3 x full scale value Short time: full scale value
100mm:
Steady: full scale value Fluctuating: 0.9 x full scale value Short time: 1.3 x full scale value
Permissible temperature

Ambient: -20 ... +60 °C
Mediium: +60 °C maximum

Ingress protection

 IP65

Temperature effect

When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of the span

Process connection

 Brass

Pressure element

 Brass, C-type or helical type
Movement Brass
Dial Aluminium, colorful, without pointer stop pin
Black lettering
Pointer Aluminium
Case Stainless steel
Ring Stainless steel
Window Plastic, glass, safety glass
Unit

bar, psi, kg/cm2, kPa, MPa
Thread G, BSP, PT, BSPT, NPT
Options Other process connection thread
Surface mounting flange
Mounting bracket


Dimensions
50mm Industrial Liquid Filled Oil Pressure Gauge Dual Scale 0 - 70 Psi

Size Dimensions in mm Weight in kg
a b b2 D1 D2 e f G h SW
50 12 30 55 55 50 5.5 - 1/4" 48 14 0.15
63 13 32 56 68 62 6.5 - 1/4" 54 14 0.21
100 15.5 48 81.5 107 100 8 30 1/2" 87 22 0.80


Ordering information
Model / Dial size / Pressure Range / Process connection / Options

50mm Industrial Liquid Filled Oil Pressure Gauge Dual Scale 0 - 70 Psi
