201 304 316L Food Grade Stainless Steel Tubing , 6mm to 600mm OD
201 304 316L Food Grade Stainless Steel Tubing , 6mm to 600mm OD
201 304 316L Food Grade Stainless Steel Tubing , 6mm to 600mm OD
201 304 316L Food Grade Stainless Steel Tubing , 6mm to 600mm OD
201 304 316L Food Grade Stainless Steel Tubing , 6mm to 600mm OD
201 304 316L Food Grade Stainless Steel Tubing , 6mm to 600mm OD
Specifications
Brand Name :
Hainer Steel
Model Number :
201，202，304，304L，316L，2205，904L etc.
Certification :
ISO
Place of Origin :
China
MOQ :
500Kgs/ one size
Price :
Negotiation
Payment Terms :
T/T, L/C at sight
Supply Ability :
2000Tons/Month
Delivery Time :
15-20 days or Stock
Packaging Details :
Plastic bag in bundle,Wooden box,etc.
Welding Line Type :
ERW
Material Number :
201，202，304，304L，316L，2205，904L etc.
Description

201 304 316L Food Grade Stainless Steel Tubing , 6mm to 600mm OD

Quick Detail:

  • Product Name: Bright Annealing 201 304 316L Stainless Steel Tube In Food Industry
  • Standard: JIS, AISI, ASTM, GB, DIN, EN
  • Model Number:316L,304,321,316L,304L,309S,310S,410,420,430,409,201,202 etc
  • Outside Diameter: 6mm to 600mm
  • Thickness: 1mm to 30mm
  • Type: Seamless Or Welded
  • Surface: Picking, Annealing, Polish, HL


Description:

  1. Product Item No.: 0090foodtube-Cosco Steel
  2. Product name: 201 202 304 316L 304l 321 410 430 stainless steel pipe
  3. Standard: ASTM A554, A312, A249, A269 and A270
  4. Material Grade:201 202 304 316L 304L 321 410 430,etc.
  5. Thickness:wide thickness: 1-30mm; Outer diameter: 6-600mm
  6. Length:6m or as required
  7. Tolerance:
    a) Outer Diameter: +/- 5%
    b) Thickness: +/- 5%
    c) Length: +/- 5mm
  8. Surface:180G, 320G, 400G Satin / Hairline(Matt Finish, Brush, Dull Finish),400G, 500G, 600G or 800G Mirror finish
  9. Test: Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT

Chemical Standard and Mechanical Propertie


Chemical Composition of Material

Material Item

201

202

304

316

430

C

≤0.15

≤0.15

≤0.08

≤0.08

≤0.12

Si

≤1.00

≤1.00

≤1.00

≤1.00

≤1.00

Mn

5.5-7.5

7.5-10

≤2.00

≤2.00

≤1.00

P

≤0.06

≤0.06

≤0.045

≤0.045

≤0.040

S

≤0.030

≤0.030

≤0.030

≤0.030

≤0.030

Cr

16-18

17-19

18-20

16-18

16-18

Ni

3.5-5.5

4-6

8-10.5

10-14

Mo

2.0-3.0

Mechanical Property

Material Item

201

202

304

316

Tensile Strength

≥535

≥520

≥520

≥520

Yield Strength

≥245

≥205

≥205

≥205

Extension

≥30%

≥30%

≥35%

≥35%

Hardness (HV)

<253

<253

<200

<200

Applications:

We,this type seamless and welded food steel tube be widely in food production all over the world

In passed many years,the factories be warmly welcome to use food bright surface both inside and outside stainless steel tubeing,in order to reach high quality from European,Japanese and others countries,we owned a set of advanced equirpment for material chemical component test,physical performance test and hydraulic test etc.

Our advantage

  1. Bright Annealing
  2. Strict tolerance control
  3. Good quality control system
  4. Good after sales services
  5. Good package
