DIN Standard 1.4301 Food Grade Stainless Steel Pipe 63.5 x 1.65mm
DIN Standard 1.4301 Food Grade Stainless Steel Pipe 63.5 x 1.65mm
Specifications
Brand Name :
Hainer Steel
Model Number :
201，202，304，304L，316L，2205，904L etc.
Certification :
ISO9001,SGS,CQC,BV, TUV etc.
Place of Origin :
China
MOQ :
500Kgs/ one size
Price :
Negotiation
Payment Terms :
T/T, L/C at sight
Supply Ability :
2000Tons/Month
Delivery Time :
15-20 days or Stock
Packaging Details :
Plastic bag one by one tube,Wooden box,etc.
Market :
European,USA,Japanese etc
Production Process :
Hot-finished and polished, Cold-finished and poliesh
Material :
DIN 17007 1.4301, 1.3406
Description

DIN Standard 1.4301 Food Grade Stainless Steel Pipe 63.5 x 1.65mm

Quick Detail:

Product Name

1.4301 Sanitary Mirror Surface Steel Pipe

Outside

19.05mm, 25.4mm,31.8mm,38.1mm etc

Wall thickness

1.0mm, 1.2mm, 1.5mm, 2.0mm etc

Buff polished

Ra<0.2-0.4μm internal diameter

Surface polished

180grit,240grit,320grit,400grit,600grit,8K etc.

Type of tube

Round tube

Seamless or welded

Seamless

Delivery condition

High-Precision mu-til cold rolled

Description:

  1. Product Item No.: 0030foodtube-Cosco Steel
  2. Product name: 1.4306 Mirror Surface Fluid Stainless Steel Tubing
  3. Length of pipe: 3000mm,6100mm
  4. Marking: Registered logo,Heat No.,Grade,Standard,Size
  5. Packing: Wooden box
  6. H.S Code: 7304.4190
  7. Fluid Tube Standard And Size:

Applications:

We,this type seamless and welded food steel tube be widely used in Food,Dairy products,Make wine,

Pharmacy bio-engineering,environment protection equipment,etc.

Specification ( Designation: ASTM A270 - 03a )

Standard Specification for: Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing

1.1 This specification covers grades of seamless,welded,and heavily cold worked welded austenitic and ferritic/austenitic stainless steel sanitary tubing intended for use in dairy and food industry and having special surface finishes. Pharmaceutical quality may be requested,as a supplementary requirements

1.2 This specification covers tubes in sizes up to and including 12 in.(304.8mm) in outside diameter

Ordering information

4.1 Quantity ( feet, meters, numbers of lengths )

4.2 Name of material ( austenitic steel tube )

4.3 Process seamless ( SML ), welded ( WLD ), or heavily cold worked ( HCW )

4.4 Size ( OD, average wall thickness )

4.5 Length ( specific or random )

4.5 Surface requireemnts

4.6 Test report required

4.7 Special requirements

4.8 Others required from customer

Our advantage

  1. Bright Annealing
  2. Strict tolerance control
  3. Good quality control system
  4. Good after sales services
  5. Good package
