Industrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal Coils
Industrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal Coils
Industrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal Coils
Industrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal Coils
Industrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal Coils
Industrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal Coils
Specifications
Brand Name :
Baosteel,TISCO，WISCO，CHINA STEEL UNION
Model Number :
Thickness 0.1mm-20mm, can be customized
Certification :
ISO9001,SGS, ASTM, ASME
Place of Origin :
CHINA AnHui
MOQ :
1ton
Price :
385-560USD
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
2 metric tons per month
Delivery Time :
3-5Days
Packaging Details :
Steel strip + kraft paper + fumigated wooden box export exquisite packaging
Keyword :
PPGI Coil Sheet
Shape :
Coil Roll
Length :
Customizable
Raw Material :
Galvanized Steel
Warranty :
According to The Use Environment
Paint Coating Thickness :
Top 8-35um,Back 3-25um
Standard :
AISI, ASTM, BS, GB, JIS, EN etc
Special Use :
High-strength Steel Plate
Surface Treatment :
Coated, Embossed, Printed
Coils Weight :
3-6MT
Port :
Shanghai
Processing Services :
Welding Punching Cutting Decoiling
Product :
Color Coated Steel Coil
Technique :
Hot Rolled, Prepainted
Grade :
DX51D, DX52D, SGCC, etc
Description

Industrial-Grade PPGI Steel Coil - High Adhesion 20-25μM Coating For Durability

Industrial-Grade PPGI Steel Coils are engineered for demanding environments where ​superior coating adhesion and ​long-term durability are non-negotiable. Featuring a ​20–25μm high-adhesion coating system (tested to ASTM D3359 Class 5B), these coils withstand abrasion, impact, and chemical exposure in industries like automotive, heavy machinery, and agricultural equipment. Compliant with ​ISO 12944, EN 10169, and JIS G3314, they combine a ​Z180–Z275 galvanized base with a ​chromium-free primer and ​polyester/polyurethane topcoat for unmatched performance in harsh conditions.

Key Advantages:

  • ​Unrivaled Adhesion: Cross-cut test rating of 5B (ASTM D3359) ensures coating integrity under stress.
  • ​Heavy-Duty Protection: Resists chipping, scuffing, and UV degradation (1,500+ hours salt spray resistance).
  • ​Custom Thickness: 0.5–3.0mm thickness (±0.03mm tolerance) for structural and lightweight applications.
  • ​Rapid Processing: Pre-treated surfaces compatible with welding, bending, and powder coating.
  • ​Global Compliance: Meets ASTM A653, ISO 1461, and DIN 55633 for international projects.
  • ​Eco-Conscious: REACH/RoHS-compliant coatings + recyclable steel core.

​2. Technical Specifications

​Parameter ​Details
​Base Material Low-Carbon Steel (C: ≤0.12%, Mn: 0.20–0.60%, Si: ≤0.05%, P/S: ≤0.025%)
​Coating Structure Hot-Dip Galvanized (Z180–Z275) + Chromium-Free Primer + Polyester/PU (20–25µm)
​Grades EN 10169 (S550GD+Z), ASTM A653 (G90), JIS G3314 (SGH440)
​Thickness Range 0.5mm–3.0mm (±0.03mm for ≤1.5mm, ±0.05mm for >1.5mm)
​Coil Dimensions Width: 700–1,500mm (±1mm), ID: 508/610mm, Max OD: 2,000mm
​Mechanical Properties Tensile Strength: 400–700 MPa, Yield Strength: 320–550 MPa, Elongation: 12–20%
​Surface Properties Gloss: 30–60 GU, roughness Ra ≤0.5µm, pencil hardness ≥2H (ISO 15184)
​Certifications ISO 12944 (C4/C5), ASTM D3359, TÜV SÜD, IATF 16949, AWS D1.3 welding standard
​Primary Applications Truck chassis, excavator panels, grain silo linings, and conveyor belt guards

​3. Competitive Advantages for Importers

Why Partner with Us?

  • ​Cost Efficiency: ​25–35% lower pricing than North American suppliers with identical specs.
  • ​Fast Turnaround: 10-day production + door-to-door logistics (Incoterms: FOB, CIF, DDP).
  • ​Zero-Defect Assurance: AI-powered coating thickness control (±2µm) + 100% bend/flange testing.
  • ​Tailored Solutions: Anti-slip textures, RFID tags for inventory tracking, and pre-cut blanks.
  • ​Global Warehousing: Strategic stockpiles in Antwerp, Dubai, and Los Angeles for 72-hour delivery.
  • ​Technical Support: Free weldability reports, corrosion simulation data, and CAD/CAM integration.
  • ​Warranty: 15-year anti-corrosion warranty + 5-year adhesion guarantee (ISO 4628-8).

Industrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal CoilsIndustrial Grade PPGI Coil Sheet Custom Galvanized Sheet Metal Coils

​4. Industrial & Agricultural Applications

Industry ​Use Cases
Automotive Manufacturing Commercial truck beds, trailer floors, and forklift body panels.
Heavy Machinery Bulldozer guards, crane counterweights, and hydraulic cylinder housings.
Agriculture Combine harvester exteriors, fertilizer spreader liners, and livestock feeder panels.
Mining & Quarrying Crusher machine covers, rock conveyor systems, and slurry tank linings.
Oil & Gas Pipeline protection sheets, drilling rig walkways, and valve casing covers.
Renewable Energy Wind turbine tower cladding, biomass boiler exteriors.
Transport Infrastructure Bridge under-deck panels, toll booth roofs, and railway cargo container liners.

FAQ

1. Who are we?

Our headquarters is located in Anhui, China. Since 2010, we have sold to the domestic market (30.00%), South Asia (10.00%), South America (10.00%), North America (10.00%), Southeast Asia (10.00%), and Africa (5.00%) , Northern Europe (5.00%), Central America (5.00%), Middle East (5.00%), Western Europe (3.00%), Oceania (3.00%), Southern Europe (2.00%), East Asia (1.00%), Eastern Europe (1.00%) . There are about 11-50 people in total in our factory.

2. How do we ensure quality?

There are always pre-production samples before mass production;

Always conduct final inspection before shipment;

3. What can you buy from us?

PPGI Steel Coil,PPGI Steel Sheet, stainless steel pipe, stainless steel coil, stainless steel strip, wear-resistant plate, galvanized steel plate

4. Why should you buy from us instead of other suppliers?

The company introduces advanced technology and equipment, and its products are exported to Western countries such as the United Kingdom and the United States. It has strong technical force and experienced technical and management personnel.

5. What services can we provide?

Accepted delivery terms: FOB, CFR, CIF, EXW;

Accepted payment currencies: USD;

Accepted payment methods: T/T, L/C, cash;

Languages spoken: English, Chinese
