0.1mm-300mm Checkered Stainless Steel Plate Hastelloy C276 Steel Plate
0.1mm-300mm Checkered Stainless Steel Plate Hastelloy C276 Steel Plate
0.1mm-300mm Checkered Stainless Steel Plate Hastelloy C276 Steel Plate
0.1mm-300mm Checkered Stainless Steel Plate Hastelloy C276 Steel Plate
Specifications
Brand Name :
WOSHANG
Model Number :
201 202 304 316 317 321 310 309 410 420
Certification :
SGS ISO ROHS
Place of Origin :
China
MOQ :
500 Kgs
Price :
Negotatable
Payment Terms :
T/T, L/C, Western Union
Delivery Time :
1000TONS PER MONTH
Packaging Details :
Standard Waterproof Package
Product Name :
Stainless Steel Plate
Tolerance :
±1%
Width :
500-1500mm Or Customize
Thickness :
0.3mm-15mm
Length :
500mm-6000mm Or Customize
Business Type :
Manufaturer
Port :
Shanghai
Price Term :
CIF CFR FOB
Description

0.1-300mm Stainless Steel Coil Cold Roll Stainless Steel Sheets plate

Product Description
"Quality is our culture."

Welcome know more about our company.

1. 15+rich experiece in stainless steel sheet,coil and all kinds of bars;

2. The company was awarded the gold product by Ali and vertified by sgs certification;

3. Competive prices with cusomer oriednted

4. Exported to more than 100 countries;

5. Fast delivery in 5 days

Any questions, pls feel free to let me know and I will reply you in 2 hours;

Looking forward to your reply!

Hastelloy C276 steel plate
Hastelloy plates are suitable for use in a variety of chemical industries containing oxidizing and reducing media. The higher molybdenum and chromium contents make the alloy resistant to chloride ion corrosion, and the tungsten element further improves the corrosion resistance. At the same time, C-276 Hastelloy tube is one of only a few materials resistant to moisture chlorine, hypochlorite and chlorine dioxide solution. It has high concentration of chloride solution such as ferric chloride and copper chloride. Significant corrosion resistance.
Application areas
heat exchangers, bellows compensators, chemical equipment, flue gas desulfurization and denitrification, paper industry, aerospace applications, acidic environments.
Classification
Hastelloyalloy is mainly divided into three series of B, C and G. It is mainly used in the case of iron-based Cr-Ni or Cr-Ni-Mo stainless steel, non-metallic materials and other strong corrosive media.
Hastelloy grade
In order to improve the corrosion resistance and cold and hot processing properties of Hastelloy, Hastelloy has undergone three major improvements, and its development process is as follows:
B series: B→B-2(00Ni70Mo28)→B-3
C series: C→C-276(00Cr16Mo16W4)→C-4(00Cr16Mo16)→C-22(00Cr22Mo13W3)→C-2000(00Cr20Mo16)
G series: G→G-3(00Cr22Ni48Mo7Cu)→G-30(00Cr30Ni48Mo7Cu)
The most widely used are the second generation materials N10665 (B-2), N10276 (C-276), N06022 (C-22), N06455 (C-4) and N06985 (G-3).

Hastelloy C276 chemical composition %wt

Element C Cr Ni Fe Mo W Si Mn S P V Co
Range ≤0.01 14.5 余量 4 15 3 ≤0.08 ≤1.0 ≤ ≤0.03 ≤0.35 ≤2.5
/16.5 /7.0 /17.0 /4.5 0.04
Melting product 0.0023 15.81 --- 5.33 15.97 3.77 0.025 0.56 <0.001 0.007 0.18 0.1

Hastelloy C276 tensile test at room temperature (20 ° C)

C276 Rm Rp0.2 A(L0=50mm) Remarks
ASTM B564 ≥690 MPa ≥283 MPa ≥40% ASTM E8M- 04
C276 tensile strength Yield strength (offset = 0.2%) Elongation (L0=50mm) Remarks
Melting result 795MPa 362MPa 64% ASTM E8M-04

Standard ASTM,AISI,SUS,JIS,EN,DIN,BS,GB
Material 201/202/301/302/304/304L/316/316L/309S/310S/321/409420/430/430A/434/444/2205/904L 2205 2507 2520
Finish(Surface) No.1/2B/NO.3/NO.4/BA/HL/Mirror
Technique Cold Rolled / Hot Rolled
Thickness 0.3mm-3mm(cold rolled) 3-120mm (hot rolled)
Width 1000mm-2000mm or customization
Length 1000mm-6000mm or customization
Application Stainless steel sheets can apply to construction field, ships building industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger,machinery and hardware fields. Stainless steel sheet can be made according to the customer's requirements. Fast delivery. Quality assured.Welcome to order.

Chemical Component

Grade C Si Mn P S Ni Cr Mo
201 ≤0.15 ≤0.75 5.5-7.5 ≤0.06 ≤0.03 3.5-5.5 16.0-18.0 -
202 ≤0.15 ≤1.0 7.5-10.0 ≤0.06 ≤0.03 4.-6.0 17.0-19.0 -
301 ≤0.15 ≤1.0 ≤2.0 ≤0.045 ≤0.03 6.0-8.0 16.0-18.0 -
302 ≤0.15 ≤1.0 ≤2.0 ≤0.035 ≤0.03 8.0-10.0 17.0-19.0 -
304 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 8.0-10.5 18.0-20.0
304L ≤0.03 ≤1.0 ≤2.0 ≤0.035 ≤0.03 9.0-13.0 18.0-20.0
309S ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 12.0-15.0 22.0-24.0
310S ≤0.08 ≤1.5 ≤2.0 ≤0.035 ≤0.03 19.0-22.0 24.0-26.0
316 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 10.0-14.0 16.0-18.0 2.0-3.0
316L ≤0.03 ≤1.0 ≤2.0 ≤0.045 ≤0.03 12.0-15.0 16.0-18.0 2.0-3.0
321 ≤0.08 ≤1.0 ≤2.0 ≤0.035 ≤0.03 9.0-13.0 17.0-19.0 -
904L ≤2.0 ≤0.045 ≤1.0 ≤0.035 - 23.0-28.0 19.0-23.0 4.0-5.0
2205 ≤0.03 ≤1.0 ≤2.0 ≤0.030 ≤0.02 4.5-6.5 22.0-23.0 3.0-3.5
2507 ≤0.03 ≤0.80 ≤1.2 ≤0.035 ≤0.02 6.0-8.0 24.0-26.0 3.0-5.0
2520 ≤0.08 ≤1.5 ≤2.0 ≤0.045 ≤0.03 0.19-0.22 0.24-0.26 -
410 ≤0.15 ≤1.0 ≤1.0 ≤0.035 ≤0.03 - 11.5-13.5 -
430 0.12 ≤0.75 ≤1.0 ≤0.040 ≤0.03 ≤0.60 16.0-18.0 -

Surface Finish Characteristics and application
2B The surface brightness and flatness of no2B is better than no2D. then through a special surface treatment to improve its mechanical properties,No2B could nearly satisfy comprehensive uses.
No.1 Polished with abrasive belt of grit#100-#200, have better brightness with discontinuous coarse stria, used as inner and external ornaments for building, electrical appliances and kitchen utensils etc.
No.4 Polished with abrasive belt of grit #150-#180,have better brightness with discontinuous coarse stria, but thinner than No3, are used as bathtub buildings inner and external ornaments electrical appliances kitchen utensils and food processing equipment etc.
HL Polished with abrasive belt of grit #150-#320 on the NO.4 finish and has continuous streaks, mainly used as buildings ornaments elevators, door of building, frontal plate etc.
BA Cold rolled, bright annealed and skin-passed, the product have excellent brightness and good reflexivity like mirror, kitchen apparatus, ornament etc.
8K The product have excellent brightness and prefer reflexivity can to be the mirror.

APPLICATION
Stainless steel has unique characteristics such as unique strength, high abrasion resistance, superior anti-corrosion performance and resistance to rust. Therefore, it is widely used in industry, food machinery, mechanical and electrical industry, household appliance industry, home decoration and finishing industry. The development prospect of stainless steel application will be more and more broad, but the development of stainless steel application largely depends on the development of its surface treatment technology.
