Specifications
Place of Origin :
Guangdong, China
Model Number :
VICTOR NMS-1500-24
Brand Name :
SZSSTH
Price :
CN¥877.11/pieces 1-499 pieces
Input Voltage :
24V
Output Voltage :
220V 230V
Output Current :
Load
Output Frequency :
50Hz/60Hz
Output Type :
Single
Size :
348x270x95mm
Type :
DC/AC Inverters
Inverter Efficiency :
95%
Weight :
4kg
Product name :
Hybrid Solar Inverter 1.5Kw
Inverter type :
Hybrid Off Grid Solar Inverter
Controller type :
MPPT Solar Controller
Communication :
WiFi/GPRS(Optional)
Battery type :
Lead Acid \ Lithium \ Gel
Protection :
Overload
Rated power :
1500VA
AC Voltage :
230VAC
Display :
LCD Display
Max PV voltage :
150V
Certificate :
CE, ROHS
Warranty :
1 year
Description

Pure Sine Wave 1.5KW 24V MPPT Hybrid Off-Gird Solar Inverter for Solar Home System Output Frequency 50Hz/60Hz ROHS Certified

Products Description
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
Product Features
1.Pure sine wave solar inverter 2.Built-in 40A MPPT solar charger 3.PVinput voltage range20-150VDC (for 1000W),30~150VDC(for 1500W)Built-in anti-dust kit for harsh environment 4.Smart battery charge design to optimize battery life 5.meet rich customized demands 6.Solar energy is provided directly to the load first
Model
VICTOR NMS-1000-12
VICTOR NMS-1500-24
RATED POWER
1000W/1000VA
1500W/1500VA
AC Input
Voltage
230VAC
Selectable Voltage Range
170~280VAC(For Personal Computers)
90~280VAC(For Home Appliances)
Frequency Range
50Hz/60Hz(Autosensing)
AC OUTPUT
AC Voltage Regulation
230VAC±5%
Surge Power
2000VA
3000VA
Efficiency(Peak) PV to IN V
98%
Efficiency(Peak) Battery to IN V
94%
Transfer Time
10ms
BATTERY
Battery Voltage
12VDC
24VDC
Floating Charge Voltage
13.5VDC
27VDC
Overcharge Protection
16VDC
32VDC
SOLAR CHARGER&AC CHARGER
Solar Charger Type
MPPT
Maximum PV Array Power
600W
1200W
MPPT Range@Operating Voltage
20~150VDC
30-150VDC
Maximum PV Array Open Circuit
Voltage solar
150VDC
Maximum Solar Charging Current
40A
Maximum AC Charging Current
40A
Maximum Solar+AC Charging
Current
80A
PHYSICAL
Dimension, D*W*H(mm)
290*240*91
Cartoon Dimension, D“W*H(mm)
340*295*145
Net Weight(kgs)
3.5
3.6
Gross Weight(kgs}
4.0
4.2
ENVIRONMENT
Humidity
5%to 95%Relative Humidity(Non-condensing)
Operating Temperature
-10℃-50℃
STANDARD
Compliance Safety
CE
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
Recommend Products
Company Profile
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
Customers' feedback
24V 1.5 Kw Pure Sine Wave Inverter For Solar Home System 50Hz/60Hz
FAQ
1)Any inquiries will be replied within 24 hours
2)Well-trained and experienced staffs to answer all your enquires influent English.

OEM and ODM available:

1)Print logo on our products.
2)Customized Specification.
3)Customized Color Package box.
4)Any your idea on our products,we can help you to design and put it into production

Before and After-sale service:

1)All products will have been quality checked strictly in test house before packing
2)All products will be well packed before shipping
3)All our products have 2-5 years warranty
and we are sure the product will be free from maintenance within warranty period

Payment term:

T/T, Western Union, Paypal,MoneyGram, L/C are available.

Shipping and delivery:

1)We have strong cooperation with DHL,TNT,UPS,FEDEX,EMS and so on.You can also choose your own shipping forwarder.
2)normal products need About 15-25 days,customized products need about 30-45 days.
