Specifications
Certification :
ISO TUV SGS BIS CE
Place of Origin :
Shandong China
MOQ :
3Tons
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,OA
Supply Ability :
5000Tons Per Months
Delivery Time :
5-15days depend on the quantity
Product name :
Seamless Alloy Steel Pipe
Standard :
ASTM, JIS, DIN, GB
Type :
Hot Rolled,Cold drawn,NPS
Pipe end :
Plain end,Beveled end,Treaded
Brand Name :
TESTE
Packaging Details :
With iron sheet to pack the steel sheet and pallet .Also make the shipping marks on each bundles.
Model Number :
20# /16Mn/ 12CrMoV /API 5L /API 5L
Price :
USD500~USD860 Per Ton
Application :
Petroleum, Chemical, Machinery, Electric Power, Shipbuilding, Papermaking, Construction
Length :
Customized
Surface Treatment :
Seamless
Technique :
Hot Rolled, Cold Rolled, Cold Drawn
High Light :
pipe
Description

ASTM A213 Grade T2 Seamless Alloy Steel Pipe

ALLOY pipe

ASTM A213 is the standard specification for seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes. Grade : T2, T5, T5b, T5c, T9, T11, T12, T17, T21, T22, T23, T24, T36, T91, T92, T122, and T911. The tubing sizes and thickness usually furnished to this specification are 1/8″(3.2 mm) in inside diameter to 5″(127 mm) in outside diameter and 0.015″ to 0.500″(0.4-12.7 mm) in minimum or average wall thickness. ASTM A213 tubes of custom-diameter may be furnished, provided such tubes comply with all other requirements of the standard specification.

GRADE

Standard Low-Alloy Steel Grade
ASTM A213

T2 T5 T5b T5c T9 T11 T12 T17 T21 T22

T23 T24 T36 T91 T122 T911

CHEMICAL COMPOSITION

Element C Mn Si P S Cr Mo
T2 0.10~0.20% 0.30~0.61% 0.50~0.81% 0.025% 0.025% 0.50~0.81% 0.44~0.65%
T5 0.15% 0.30~0.60% 0.50% 0.025% 0.025% 4.0~6.0% 0.44~0.65%
T5b 0.15% 0.30~0.60% 1.00~2.00% 0.025% 0.025% 4.0~6.0% 0.44~0.65%
T5c 0.12% 0.30~0.60% 0.50% 0.025% 0.025% 4.0~6.0% 0.44~0.65%
T9 0.15% 0.30~0.60% 0.25~1.00% 0.025% 0.025% 8.0~10.0% 0.90~1.10%
T11 0.05~0.15% 0.30~0.60% 0.50~0.10% 0.025% 0.025% 1.0~1.5% 0.44~0.65%
T12 0.05~0.15% 0.30~0.61% 0.50% 0.025% 0.025% 0.8~1.25% 0.44~0.65%
T17 0.05~0.25% 0.30~0.61% 0.15~0.35% 0.025% 0.025% 0.8~1.25% -
T21 0.05~0.15% 0.30~0.60% 0.50~0.10% 0.025% 0.025% 2.65~3.35% 0.80~1.06%
T22 0.05~0.15% 0.30~0.60% 0.50% 0.025% 0.025% 1.9~2.6% 0.87~1.13%
T23 0.04~0.10% 0.10~0.60% 0.50% 0.03% 0.010% 1.9~2.6% 0.05~0.30%
T24 0.05~0.10% 0.30~0.70% 0.15~0.45% 0.02% 0.010% 2.20~2.60% 0.09~1.10%
T36 0.10~0.17% 0.80~1.20% 0.25~0.50% 0.03% 0.025% 0.30% 0.25~0.50%
T91 0.07~0.14% 0.30~0.60% 0.20~0.50% 0.02% 0.010% 8.0~9.5% 0.85~1.05%
T92 0.07~0.13% 0.70% 0.50% 0.02% 0.010% 8.5~9.5% 0.30~0.60%
T122 0.07~0.14% 0.30~0.60% 0.50% 0.02% 0.010% 10.0~11.5% 0.25~0.60%
T911 0.09~0.13% 0.30~0.60% 0.10~0.50% 0.02% 0.010% 8.5~9.5% 0.09~1.10%

ALLOYING ELEMENTS

The addition of Molybdenum (“Moly”) increases the strength of the steel and its elastic limit, enhance the steel resistance to wear, its impact qualities, and the hardenability. It also improves the resistance to softening, makes chromium steel less prone to embrittlement and prevents pitting.

Chromium, a key element also for stainless steel alloys, prevents steel oxidation at elevated temperatures and increases the resistance of steel to corrosion. It enhances the tensile, yield, and hardness properties of low-alloy pipes at room temperatures.
Other alloying elements, present in various degrees in pipes of all grades are:

  • Aluminum: decreases oxygen from steelmaking
  • Boron: used to produce fine grain size and enhance steel hardness
  • Cobalt: used to enhance the steel’s heat and wear-resistance
  • Manganese: gives better steel hardenability
  • Nickel: Enhances toughness, hardenability and impact strength at low temperatures
  • Silicon: decreases oxygen, enhances hardenability and toughness
  • Titanium: prevents precipitation of chromium carbide
  • Tungsten: refines steel grain size and enhance the steel hardness, especially at high temperatures
  • Vanadium: gives steel enhanced fatigue resistance

As mentioned, low-alloy steels have a total amount of alloying elements below 5%; high alloy steel has a higher percentage of these elements.
