Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Decorative Phosphor Bronze Mesh Cloth For Faraday Cage Long Working Life
Specifications
Brand Name :
MILESEN
Model Number :
100MESH
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
10 ROLLS
Payment Terms :
L/C, T/T
Packaging Details :
each roll wrapped with pvc cloth and water proof paper, then put into wood carton
Price :
Negotiable
Material :
Phosphor Bronze Wire
Length :
30m/roll
Type :
Woven
Width :
0.5 - 3.0m
Mesh :
6-200mesh
Application :
Filter
Feature :
Strength
Hole shape :
Square Hole
Description

Phosphor Bronze Wire Cloth For Faraday Cage

Product Description

Material of Phosphor Bronze Wire Mesh:Phosphor bronze wire is an alloy wire of copper, tin and phosphor, which offers good corrosion resistance,wear resistance and tear resistance and is frequently used in the making for fine mesh cloth. A kind of copper alloy, with 4% to 9% tin, approximately 0.25% phosphorous, the balance is copper.

Bronze has a higher corrosion resistance, abrasion resistance, maximum working temperature of 250 ℃, bronze is an alloy of copper, with good electrical properties, easy to heat, to ensure safety at the same time have a strong fatigue resistance, excellent mechanical processing performance, widely used in copper casting, solder and other fields.

Phosphor bronze is well regarded for it's strength and toughness compared to the natural copper. This is due to the levels of tin in the alloy.Woven wire mesh and wire cloth made of phosphor bronze wire are mainlyused as fine wire cloth in a number of industries.Phosphor bronze wire mesh is frequently used in sieving diversified pellet, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.

Feature of the Phosphor Bronze Wire

· Good electrical conductivity.
· Heat transfer performance.
· Corrosion Resistant and Non-magnetic.
· Abrasion resistance and ​Low ductility.
· Acid and Alkali Resistant.
· High Air Pemeability.
· Easy Clean Ability.

· Corrosion-resistant.

Application of the Phosphor Bronze Wire

1. Industrial applications
Shipping: As good seawater corrosion resistance.
Cars: Mainly used radiator, brake system piping, fittings and accessories, such as.
Railway: motors, electrical and signal systems on the train.
Aircraft: aircraft wiring, hydraulic, cooling and pneumatic systems need to use copper
2. Electronic applications
Electronical vacuum devices: HF and UHF launch tube, waveguide, magnetron, etc, which require high-purity oxygen-free copper and oxygen-free copper dispersion strengthened
Printed circuit: used for the circuit connection.
3. IC: microchip.
Lead Frame: it has become an important material for the lead frame.

Spec for our products

Mesh Wire Dia. (MM) Opening(mm)
SWG mm inch
6mesh 22 0.711 0.028 3.522
8mesh 23 0.610 0.024 2.565
10mesh 25 0.508 0.020 2.032
12mesh 26 0.457 0.018 1.660
14mesh 27 0.417 0.016 1.397
16mesh 29 0.345 0.014 1.243
18mesh 30 0.315 0.012 1.096
20mesh 30 0.315 0.0124 0.955
22mesh 30 0.315 0.0124 0.840
24mesh 30 0.315 0.0124 0.743
26mesh 31 0.295 0.0116 0.682
28mesh 31 0.295 0.0116 0.612
30mesh 32 0.247 0.011 0.573
32mesh 33 0.254 0.010 0.540
34mesh 34 0.234 0.0092 0.513
36mesh 34 0.234 0.0092 0.472
38mesh 35 0.213 0.0084 0.455
40mesh 36 0.193 0.0076 0.442
42mesh 36 0.193 0.0076 0.412
44mesh 37 0.173 0.0068 0.404
46mesh 37 0.173 0.0068 0.379
48mesh 37 0.173 0.0068 0.356
50mesh 37 0.173 0.0068 0.335
60X50mesh 36 0.193 0.0076 -
60X50mesh 37 0.173 0.0068 -
60mesh 37 0.173 0.0068 0.250
70mesh 39 0.132 0.0052 0.231
80mesh 40 0.122 0.0048 0.196
90mesh 41 0.112 0.0044 0.170
100mesh 42 0.012 0.004 0.152
120X108mesh 43 0.091 0.0036 -
120mesh 44 0.081 0.0032 0.131
140mesh 46 0.061 0.0024 0.120
150mesh 46 0.061 0.0024 0.108
160mesh 46 0.061 0.0024 0.098
180mesh 47 0.051 0.002 0.090
200mesh 47 0.051 0.002 0.076
