Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving
Specifications
Brand Name :
PASSION LED DISPLAY
Model Number :
STAGE LED DISPLAY
Certification :
CE ROHS
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
5000 square meter per month
Packaging Details :
Flight case and wooden case
Usage :
Outdoor
Tube Chip Color :
Full Color
Display Function :
Video
Brightness :
5500CD/sqm
Refresh Rate :
1000~2000Hz/S
IP rate :
65
Description

Lightweight Large LED Display Customized Size Low Failure Rate Energy Saving

Large LED Display Details

  • High quality LED chip and high anti-static electricity capacity.
  • Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led DIP lights, the brightness is more than 7000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle

Specification of LED Display Details:

LED Module Pitch/mm PH4.81 PH5.95 PH6.25 PH8.928
Module size/mm 250*250 250*250 250*250 250*250
Density of pixel/(dots/m2) 43264 28224 25600 12544
Pixel composition 1R1G1B 1R1G1B 1R1G1B 1R1G1B
Led encapsulation SMD 3 IN 1 SMD 3 IN 1 SMD 3 IN 1 SMD 3 IN 1
Resolution of module 52*52 42*42 40*40 28*28
LED Screen Optimum viewing distance 3~38M 4~40M 5~45M 7~50M
View angle H:±160°;V±120° H:±160°;V±120° H:±160°;V±120° H:±160°;V±120°
Average power consumption 600W/sqm 400W/sqm 300W/sqm 300W/sqm
Max power consumption 1600W/sqm 1000W/sqm 900W/sqm 700W/sqm
Module quantity 2*2pcs
Size of cabinet/mm 500*500
Resolution of cabinet 104*104 84*84 80*80 56*56
Cabinet Material die-casting aluminum cabinet
Weight of cabinet 9Kg
Driving method 1/13 scan constant current 1/7 scan constant current 1/10 scan constant current 1/7 scan constant current
Frame frequency / Hz/S ≥60
Refresh frequency/ Hz/S 800~2000
Brightness 5500cd/m2 5500cd/m2 6000cd/m2 6000cd/m2
Operating temperature –25C°～65C°
Storage temperature –40C°～70C°
Operation humidity 10%-90%
Storage humidity 10%-90%
IP Rrating (Front/Rear) IP65/ IP54
Working vlotage AC220V / AC110V ±10%
Grey scale/color depth displaying colors≥16.7M(synchronized); 14bits
Brightness adjustment 256 levels of each color(manually)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
Average of non-failure life ≥50,00h
Life span ≥100,000h
Functionaless dot rate ≤0.0001
Control distance CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km
