Specifications
Brand Name :
PASSION
Model Number :
P3.91mm
Certification :
CE ROHS
Place of Origin :
SHENZHEN , CHINA
MOQ :
Negotioation
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
5000 square meter per month
Delivery Time :
15 ~ 20 working days
Packaging Details :
Flight Case & Wooden Case
Other Name :
Stage LED Display
Panel Weight :
28Kg/SQM
Display Function :
Video, Picture
Application :
Indoor and outdoor stage
Material :
Die casting aluminum
Referesh rate :
3840Hz
Description

500*1000mm Aluminum Led Video Display Panel Rental Use Stage Background Led Display

Product features of RGB Stage LED Display:

1. High quality LED chip and high anti-static electricity capacity.

2. Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led, the brightness is more than 2000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle.

Supply Ability of RGB Stage LED Display :

5000 Square Meter/Square Meters per Month

Specification of RGB Stage LED Display:

Indoor slim rental P3.91mm LED screen (unit module size: 250mm * 250mm and unit cabinet size: 500mm * 1000mm)
LED Module Pitch/mm PH3.91
Module size/mm 250*250
Density of pixel/(dots/m2) 65536
Pixel composition 1R1G1B
Led encapsulation SMD2121 3 IN 1
Resolution of module 64*64
LED Screen Optimum viewing distance 3~38M
View angle H:±160°;V±120°
Average power consumption 300W/sqm
Max power consumption 800W/sqm
Module quantity 2* 4pcs
Size of cabinet/mm 500*1000
Resolution of cabinet 128*256
Cabinet Material die-casting aluminum cabinet
Weight of cabinet 13Kg
Driving method 1/16 scan constant current
Frame frequency / Hz/S ≥60
Refresh frequency/ Hz/S 1920
Brightness 1000cd/m2
Operating temperature –20C°～60C°
Storage temperature –40C°～70C°
Operation humidity 10%-90%
Storage humidity 10%-90%
IP Rrating (Front/Rear) IP43
Working vlotage AC110V ±10%
Grey scale/color depth displaying colors≥16.7M(synchronized); 14bits
Brightness adjustment 256 levels of each color(manually)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system Novastar
Average of non-failure life ≥50,00h
Life span ≥100,000h
Functionaless dot rate ≤0.0001
Control distance CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km

FAQ :

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

Q4: What is LED display?

A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.
