Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels
Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels
Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels
Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels
Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels
Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels
Specifications
Brand Name :
PASSION LED
Model Number :
P1.25mm
Certification :
CE , RHos
Place of Origin :
Shenzhen , China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
10000PCS/month
Delivery Time :
5 days sine the deposit arrival
Packaging Details :
Carton or Wooden Case
Unit Size :
192mm * 192mm
Pixels :
1.25mm
Display function :
Video,Graphics,Text,app,static
Screen dimension :
Customized
Tube chip color :
Full Color
Application :
Adervertising,Live Show,Competition/Advertising,Super Mall,rental led display
Description

PH1.25 LED Display Module Panel, No Need a Back Cover Led Display Screen Module

High definition display
It delivers a truly amazing pciture in every details with extrodinary pixels producing an image that is HD quality in an LED screen

Natural Color
16bits Gray processing techology,with 65536 grayscale,excessive nature,according to the video picture of extremely fine texture,looked more comfortable.

Pixel Configuration SMD1010
Pixel pitch(mm) 1.25mm
Pixel density(dots/m2) 640000
Module resolution(W×H) 160×135
Module size (mm) 200(W)×168.75(H)
Module weight (kg) 0.8
Maximum power consumption of the module(W) 40
Module of cabinet (W×H) 3×2
Cabinet resolution(W×H) 480×270
Cabinet size (mm) 600(W)×337.5(H)×86(D)
Cabinet area(m2) 0.2
Cabinet weight (kg) 7.8
Cabinet level up degree(mm) ≤0.2
Maintenance mode Front/Rear
Cabinet raw material Die-casting aluminum
Single-point brightness correction YES
Single - point color correction YES
White Balance Brightness (nits) ≥800(6500K)
Color Temperature (K) 3200—9300 (adjustable)
Viewing Angle (Horizontal / Vertical) 160/160
Deviation of center distance of light - emitting <3%
Brightness / chromaticity uniformity ≥97%
Contrast 4000:1
Peak power consumption (W / m2) 800
Average power consumption (W / m2) 250
Power supply requirements AC90~264V,frequency 47-63(Hz)
Frame rate (Hz) 50&60
Drive mode Constant drive,1/27
Grayscale level 65536
Refresh rate (Hz) ≥3840
Number of color processing bits 16bit
Video playback capabilities 2KHD,4KHD
Operating temperature / humidity range (℃ / RH) -20 – 60 / 10%-85%RH
Storage temperature / humidity range (℃ / RH) -20 – 60 / 10%-85%RH
Applicable standards CCC,CE,RHos

Top-lever brightness control
Expansion of brightness adjustment range increase the brightness and contrast ratio of picture. This function can fully perform delicate change of brightness,so it can present a vivid clear picture to audience.


Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels

1. Gapless installation, wider viewing angle, good color uniformity

Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels


2. Soft images,green and environmental protection

Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels


3. High refresh rate, remove ghost without trailing

Small Spacing Led Video Wall Module , Indoor Full Color Led Screen 1.25mm Pixels


4. Locating slot work with dowel pin to ensure good flatness

Application of HD LED Display:

PASSION LED P1.92 indoor HD LED display is also called HD LED TV as one of the most popular led display used in TV Studio, Entertainment Center, Surveillance Room, Indoor meeting hall. With small cabinet size: 400 x 300mm, Die-casting aluminum structure with high precision and cooling effect.


After-sale Service:


Installation servive, usually we don't take charge of installing overseas, but we can
provide technical support for you. if you need installation service, we can send our
technicians to your country, but the customers need take charge of the cost
Lifetime free maintenance and software upgrade service.
we will reponse you in 8 houres if you have any question about the led screen,
maintenance guidance and problem solution supplied in 48 hours.
Providing customer with the loading program, so they can use as soon as they install the
led screen,don't need to debug again
Free technical training for how to use and handle the software.
Customer satisfaction tracking report.
