50W LED Moving Head Spot Light Professional LED Stage Lighting
Quick Detail:
Stepping from 30W, Color Imagination insists on developing another
LED moving head spot with more intelligent features like traditional
spot. Right now it comes to reality. SI-050 is featuring a 50W Luminus
white LED(CST-90), 7 colors, 7 gobos, 3-facet rotatable prism and auto
focus. It’s very compact made by a fireproof body. It is a small fixture but
for big performances. The smart LEDSPOT 50 can be used anywhere
from small medium discos, to exhibitions, pubs, band performers, etc.
Description:
Luminus 50W white LED (CST-90)
50,000 hours lifespan and low power consumption
16 bit smooth and precise resolution for PAN/TILT movement
540°/630°pan and 270°tilt movement
Scan position memory, auto reposition after unexpected movement
1 color wheel with 7 colors plus open
Rainbow effect with speed adjustable
7 gobos plus white with speed adjustable, stream effect, dithering effect and
rotatable clockwise or anticlockwise (1glass gobo)
1 rotatable 3-facet prism with speed adjustable and variable direction
Gobo size 28.9mm (external dimensions) / 23mm (inner dimensions)
2 meter to infinite electric focus
15° projection angle
0-100% linear dimmer with 1-18 times/sec high speed electronic strobe
LED shutter
13 DMX channels USITT DMX-512
DMX512, master-slave and sound activated controllable or auto operation
Blue background LCD display
IEC power connector IN
45°C max ambient temperature
IP20 protection rating
55dB at 3’dB rating
3-pin or 5-pin DMX connectors
Applications:
Disco and Club
Live performance
Stage show
Specifications:
Input Voltage: | AC90-260V 50/60Hz |
LED Quantities: | 1*50W Luminus white LED |
Control Signal: | DMX512, master-slave and sound activated or auto operation |
Control Channel: | 113 DMX Channels USITT DMX-512 |
Power Consumption: | 135W |
Dimensions: | 278(D)*301(W)*444(H)mm |
Packing Dimensions: | 490(D)*370(W)*375(H)mm |
Net Weight: | 11kg |
Gross Weight: | 14kg |
