3 Facet Prism 150 Watt Mini Size Moving Head Led Spot For Stage Show

The MINISPOT 150 features a 7500K 150W LED with high intensity and efficiency. It produces very high light output, through a specific 13.2° optic system. The PAN/TILT integrates in fast and quiet movement. It
offers a full complement of professional characteristics, including a rotating gobo wheel, static gobo wheel, color wheel, a 3-facet prism,linear electronic focus, 0-100% linear LED dimmer, variable speed

shutter/strobe.

Smaller---very compact in size and weight
Better---very high in output (5230LUX@5m)

Specification:

1. Wireless System Built-in
2. Optional Versions: White Case/Back case
3. Input Voltage:AC90-260V 50/60Hz
4. LED Quantities:1*150W white LED
5. Control Signal:DMX512, master-slave and sound activated or auto
6. operation
7. Control Channel: 14/12/16 DMX channels USITT DMX-512
8. Dimensions:183(D)*298(W)*410(H)mm
9. Packing Dimensions:270(D)*370(W)*590(H)mm
10. Net Weight: 9.5kg
11. Gross Weight: 11kg

Description:

1. A 150W white LED lamp, 7500K
2. 50000 hours life span and low power consumption
3. 8/16 bit smooth and precise resolution for PAN/TILT movement
4. 360°/540°/630° PAN and 90°/180°/270° TILT movement
5. PAN/TILT inversion available
6. Scan position memory, auto reposition after unexpected movement
7. Specific high precision glass optic system with 13.2° projection angle
8. Improved optics and flat beam field
9. 1 rotatable gobo wheel with 6 rotatable and interchangeable gobos
10. plus open
11. with speed adjustable, stream effect, dithering effect and rotatable
12. clockwise or anticlockwise
13. Gobo size 23.9mm (external)/15mm (inner)
14. Static gobo wheel with 11 gobos plus open
15. Color wheel with 7 colors plus open
16. Variable direction rainbow effect with speed adjustable
17. 2~15 meter electric focus
18. 3-facet prism with variable speed and direction
19. 0-100% smooth linear LED dimmer
20. 1~25T/sec high speed LED shutter/strobe effect with variable speed
21. Preset variable/random strobe and dimming pulse effect
22. 14/12/16 DMX channels USITT DMX-512
23. DMX512, master-slave, and sound activated controllable or auto
24. operation (7 built-in programs)
25. DMX recorder and edit function integrated
26. Blue LCD display
27. POWRECON connector IN/OUT
28. 3-pin XLR connectors IN/OUT
29. Low noise fan cooling system
30. Constant temperature readout and management function
31. 45°C max ambient temperature
32. 55dB at 3’dB rating
33. 1*1/4 turn fastening Omega clamp
34. 1*Safety attachment point

Applications:

TV studio

Road shows

Disco and Club

Live performance

Stage show
