Dustproof Indoor Full Color LED Display , P3 LED Video Wall On Rent 120° Viewing Angle
Dustproof Indoor Full Color LED Display , P3 LED Video Wall On Rent 120° Viewing Angle
Specifications
Brand Name :
HJY
Model Number :
P3
Certification :
CE FCC
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000sqm per month
Delivery Time :
15-20 days after receiving deposit
Packaging Details :
flight case
Module size :
192*192mm
Panel pixel(dot) :
64*64dot
Working Voltage :
AC 220V/110V
Operating Temperature :
-20°C~+60°C
Driving Mode :
1/32 Scan Constant Current
Brightness :
1200cd/square meter
Description

P3 indoor rental led display full color rental stage led display indoor

Module Parameter:

Pixel pitch 3mm
Pixel Density 27,777 dots/m²
Pixel configuration 1R1G1B
LED type 3-in-1 black SMD2121
Module size 192*192mm
Module weight 298g
Module resolution 64*64dots
Module quantity 27.13 pcs/m²
Min. Viewing Distance ≥3m
Brightness ≥1200 cd/m²
Viewing Angle H≤120° V≤120°
Driving Mode 1/32 scan constant current driving
Interface HUB75
Input voltage 4.8-5.5VDC
Max. Power Consumption 1200 w/m²
Avg. Power Consumption 600 w/m²
Max. Current 7-7.5A
Frame rate 60 frames/s
Refresh Rate ≥3840Hz
Defective Dots Rate <0.0001 (LED display line standard: ≤ 0.0003)
Decay Rate ≤5%/year
Brightness Conformity >95%
MTBF ≥10000 hours
Lifespan ≥50000 hours
Protective function

Over-heat/Over-load /Power-down /Power-leakage/Lightning

-protection etc.
Operating Temperature -20℃~+50℃
Operating Humidity 10-85% no condensation
Storage Temperature -30℃~+60℃
Storage Humidity 10-95% no condensation
Control System Parameter
Color temperature Adjustable by software
Brightness control 256 levels, automatic adjustment.
Control way Computer, real-time, off-line, wireless, network etc.
Communication Distance Cat5 UTP 100 meters, max. 130 meters; or optical fiber.

* Die-casting aluminum, secure and nice in constitution.

* No fans, mute when operation.

* Dustproof, IP43.

* High refresh rate and high gray depth.

* Completely black LED with high contrast.

* Standard cabinet size is 576*576mm.

* Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the image won't be out of shape and color cast between the rang.

* Exactly connected and easy to install and dismount.
