High Resolution Full Color LED Display Video Wall 1500nits Brightness IP 54 Waterproof
High Resolution Full Color LED Display Video Wall 1500nits Brightness IP 54 Waterproof
High Resolution Full Color LED Display Video Wall 1500nits Brightness IP 54 Waterproof
High Resolution Full Color LED Display Video Wall 1500nits Brightness IP 54 Waterproof
High Resolution Full Color LED Display Video Wall 1500nits Brightness IP 54 Waterproof
High Resolution Full Color LED Display Video Wall 1500nits Brightness IP 54 Waterproof
Specifications
Brand Name :
HJY
Model Number :
P5
Certification :
CE FCC
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 square meter per month
Delivery Time :
15-20 days after receiving deposit
Packaging Details :
wooden case
Color :
full color
Brightness :
1500nits
Led :
2727
Led module size :
320*160mm
led module resolution :
64*32 dot
Warranty :
2 years
Description

indoor HD led display panel,P5 indoor full color led display led video wall

Specification

configure Specification Parameter
Pixel Dot Pitch 5mm
Pixel Configure 1R1G1B
Pixel/SQM 40000Pixel/m²
LED Lamp LED TYPE SMD 3528
Led Brand Kinglight
Wavelength & Brightness Red:620-622.5nm;>300mcdGreen:520-522.5nm;>600mcdBlue:465-467.5nm;>110mcd
Module Module Resolution 64Pixel * 32Pixel
Drive Mode Constant Current Drive
Scanning Method 1/16 Scanning
Module Dimension 320mm(Width)x160mm(Height)
Drive IC MBI5124(Or other Similar IC)
LED & Drive Composition Light-Drive Combo
Refresh Rate >1500HZ
Cabinet Cabinet Thickness 100mm
Cabinet Construction Normal Standard Cabinet
Cabinet Assembly Connecting Sheet
Cabinet Color(Front/Back) Black,Grey
Aviation Plug wp20
Maintenance Mode Back Maintenance
Cabinet Material Spcc1.5
Cabinet Dimension 640X640X100mm
Power Supply China Power Supply
LED Screen Viewing Angle Horizontal : 120 ° Vertical: 120 °
Brightness >1500cd/m²
Best Viewing Distance 5~25m
LED Life 100,000Hours
Maximum Power 700w/m²
Average Power 300w/m²
Input Voltage 220V±10% Or 110V±10%
Operation Environment Temperature: —20°C~60°C; Humidity: 10%~95%
Protection Grade IP 54
LED Screen Weight 35kg/m2

For our indoor HD led display panel,P5 indoor full color led display led video wall Installation:

1. We can assist the training and technical support for the customer in the factory, if the customer requires so.

2. We could send our engineer to guide the installation for you. But the relevant cost should be paid by your esteemed company.

3. Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.

High Resolution Full Color LED Display Video Wall 1500nits Brightness IP 54 Waterproof
