Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95
Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95
Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95
Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95
Specifications
Brand Name :
HJY
Model Number :
P5.95
Certification :
CE FCC
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000sqm per month
Delivery Time :
15-20 days after receiving deposit
Packaging Details :
Flight case
Pixels :
5.95mm
Led module size :
250*250mm
Brightness :
5000nits
Cabinet material :
die casting aluminum
Certificate :
CE FCC
Life span :
1000000 hours
Description

large image full color curve stage led display P5.95 outdoor rental led display 3 in 1

No. LED Type SMD3535
1 Pixel Pitch 5.95mm
2 Scan method 1/7 Scan
3 Driving method MBI 5124
4 Module Resolution 42dots*42dots
5 Module dots 1764dots
6 Module size (width*height) 250*250mm
7 cabinet size (width*height) 500*500mm/500*100mm
8 Cabinet resolution 84*84/84*168dots
9 Pixel Density 28224dots/m2
10 Cabinet raw material Aluminum
11 Brightness 6000cd/ m2
12 Refresh Rate >1920Hz
13 Repetition Frequency 60fps
14 Input Voltage AC220V/50Hz or AC110V/60Hz
15 Power consumption(Max/Average) 1036/415W
16 Weight 13kg/pcs
17 Life span >100,000 hours
18 IP degree IP65
19 Working temperature -20~60
20 Control method synchronous or asynchronous


Module Photos:250mm*250mm

Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95

Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95


Cabinet Photo: 500mm*1000mm/500*500mm

Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95


Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95

Large Image Full Color Stage Curved Outdoor Advertising Led Display Screen P5.95

The unique hexagon structure design, flat and firm


The back of the cabinet modules adopts the hexagon structure design concepts. This kind of aluminum structure ensures the feature of firmness and flatness to the largest degree. The whole screen is of typical feature after being assembled.

HD image brings you more perfect visual experience

The smallest pixel pitch of this series can be 4.81mm. The image is of very high definition. Even viewing in close range, the image will show no obvious pixel grainy. So it applies to outdoor installation perfectly.

Fast installation, high precision and less weight

Fast lock system, 80% higher efficiency in installation. Die-casting aluminum cabinet, high precision and less weight.

Brightness are adjustable

Be able to adjust the screen brightness(600-6000nits) based on ambient light changes, greatly reducing your opearating costs


Support All Media Format and Display Mode

Support all media format, also support DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program, VCD/DVD and live show. Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet. Hotplug in power supply.
