High Definition Outdoor Led Screen Hire , P3.91 Stage Background Led Screen
High Definition Outdoor Led Screen Hire , P3.91 Stage Background Led Screen
High Definition Outdoor Led Screen Hire , P3.91 Stage Background Led Screen
High Definition Outdoor Led Screen Hire , P3.91 Stage Background Led Screen
Specifications
Brand Name :
hjy
Model Number :
p3.91
Certification :
CE FCC RISH
Place of Origin :
shenzhen
MOQ :
negotiation
Price :
negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000squ
Delivery Time :
15 work days
Packaging Details :
wooden case
usage :
outdoor
pixels :
3.91
brightness :
6500
cabinct size :
500X500,500X1000
led chip :
Epistar
led configurati :
SMD 1921
life span :
100000 hours
warranty :
2 years
module size :
250X250
refresh rate :
1920
model number :
3.91
Description

P3.91 outdoor rental led display screen 500x500,500x1000 box tank high definition display

main model P3.91 P4.81 P5.95 P5 P6 P8
module pixel pitch (mm) 3.91 4.81 5.95 5 6 8
LED lamp model SMD1921 SMD2727 SMD2727 SMD2727 SMD3535 SMD3535
module size (mm) (W*H) 250*250 250*250 250*250 320*160 192*192 256*128
module resolution (W*H) 64*64 52*52 42*42 64*32 32*32 32*16
Driving mode Constant current
scan mode 1/8 1/13 1/7 1/8 1/8 1/4
cabinet material Die-casting Aluminum
standard cabinet size(W*H*T) 500*1000*95 500*1000*95 500*1000*95 640*640*95 576*567*90 512*512*90
Cabinet Resolution(W*H) 128*256 104*208 84*168 128*128 96*96 64*64
Cabinet module number 2*4 2*4 2*4 2*4 3*3 2*4
IP Grade IP65/54
Display pixel Density (dot/m2) 65536 43264 28224 40000 27776 15625
brightness (CD/m2) 6000 5500 6000 5500 5000 6500
Max consumption (W/M2) 800 750 700 750 750 800
Average Consumption (w/cabinet) 400 360 350 360 360 400
best viewing distance (m) >4 >4.8 >4.8 >5 >6 >8
view angle H:120;V120 　
system specification Soft ware ED Studio nova/linsn 　
control mode Synchronization or Asynchronization 　
Refresh rate 1200-1920HZ/S 　
gray level 16bit per color 　
repetition freguency 50-60HZ 　
brightness Adjustment 256 Grade 　
signal input HDMI,DVI,VGA,RF,S-Video,RGB,RGBH,YUV,YC&Conpasition.etc 　
Operation parameter working voltage AC110V/220V 　
working temperature 50℃ 　
life span time 100000 hours 　

High Definition Outdoor Led Screen Hire , P3.91 Stage Background Led Screen

High Definition Outdoor Led Screen Hire , P3.91 Stage Background Led Screen

High Definition Outdoor Led Screen Hire , P3.91 Stage Background Led Screen

??? How to help client choose auitable display?

  1. Specific application scenario
  2. Viewing distance requirement
  3. Display brightness requirement
  4. Specific installation environment
  5. Budget and cost control

??? what about your technical support?

Proffessional engineers are on standby ,can offer guidance ,on site

technical support as required

??? what’s the control system ?

For synchronization control :Nova,linsn or mooncell control system

For asynchronous control:Onbon or xixun control system

??? what’s the warranty of your LED Display ?

We provide 2 years warranty and conditioned lifetime technical support.

??? what’s your payment method ?

T/T 30% as deposit,balancing before delivery
