50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
Specifications
Brand Name :
JN
Model Number :
50MM 50.8MM 70MM 80MM
Certification :
SGS ISO
Place of Origin :
China
MOQ :
500kg
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram,Paypal, L/C, D/A, D/P
Supply Ability :
25 Tons per Month
Delivery Time :
7-15 days
Packaging Details :
Ploy bag+25kg carton box+1000kg wooden box
Product Name :
Harden Low Carbon Steel Balls
Grade :
G1000
Hardness :
HRC25
Density :
7.82g/cm3
Young's Modulus :
200GPa
Application :
Seat Slides
Description

50MM 70MM 80MM Solid Harden Carbon Steel Ball For Rolling Bearings 50.8MM

Carbon steel balls suppliers can provide a wide range of high-quality components

in a vast range of sizes for numerous applications.

Carbon steel bearing balls such as the AISI 1010/1015 types of

cemented balls are ideal for use as furniture bearings and can be found

in drawer rails or sliding rails, among other products, while low carbon balls

such as type 1010 and 1015 can be used in stirrers and mixers in

non-aggressive environments, in welding appliances or as curtain mechanisms.

Chemical Composition

Type
%C
%Si
%Mn
%P
%S
1010
0.08-0.13
0.10-0.35
0.30-0.60
0.040 max
0.050 max
1015
0.12-0.18
0.10-0.35
0.30-0.60
0.040 max
0.050 max

Mechanical Properties

Property
Type
U.o.M.
Values
U.o.M.
Values
Hardness
Mechanical
[HRC]
55 - 65
-
-
Ultimate tensile strength
Mechanical
[MPa]
300 - 400
[psix10^3]
43 - 58
Service temperature
Thermal
[ºC]
-40 / 500
[ºF]
-40 / 932

International Standards

ITA
USA
GER
FRA
UK
RUS
CHN
JPN
C10
1010
1.1121
CC10
040A10
10
10
S10C
C15
1015
1.1141
XC12
080M15
15
15
S15C

Physical / mechanical / thermal / electric / magnetic properties
Property
Symbol
U.o.M.
Type
Notes
Values
Density
δ
[g/cm3]
Physical
Room temp.
7.82
Young's modulus
E
[GPa]
Mechanical
-
200
Specific heat
c
[J/kg-K]
Thermal
Room temp.
468
Coefficient of linear thermal expansion
α
[10^-6/ºC]
Thermal
(ΔT=0-100°C)
11.8
Thermal conductivity
λ
[W/(m·K)]
Thermal
Room temp.
57.9
Electric resistivity
ρ
[Ω*m*10^-9]
Electric
-
155
Relative magnetic permeability
µ
-
Magnetic
Ferromagnetic
> 500

50 MM 70 MM Solid Hardened Steel Balls , 50.8 MM Round Steel Balls 7.82g/Cm3
